Description
The Crestron TSS-1080-W is a modern 10.1-inch room scheduling touch screen designed to streamline meeting space management across enterprise environments. Mounted outside conference rooms, huddle spaces, or shared work areas, it provides a clear, real-time display of room availability while enabling seamless scheduling interactions.
With a high-resolution 1920 x 1200 display, responsive capacitive touch interface, and enterprise-grade connectivity, the TSS-1080-W delivers a reliable and intuitive user experience. It integrates effortlessly with popular scheduling platforms such as Microsoft 365, Google Calendar, and other third-party applications, ensuring consistent and efficient room booking workflows.
Engineered for flexibility and performance, the device supports both wired and wireless connectivity, PoE+ power, and advanced security protocols. Its sleek white finish complements modern office aesthetics while offering robust functionality for high-demand corporate environments.
| Specification | Details |
|---|---|
| Display Type | TFT active matrix color LCD |
| Screen Size | 10.1 in. (257 mm) diagonal |
| Resolution | 1920 x 1200 (WUXGA) |
| Aspect Ratio | 16:10 |
| Brightness | 350 to 400 nits |
| Contrast Ratio | 1000:1 |
| Color Depth | 24-bit, 16.7 million colors |
| Touch Technology | Projected capacitive, 5-point multitouch |
| Viewing Angle | ±80° horizontal and vertical |
| Virtual Controls | 6 configurable on-screen buttons |
| Supported Scheduling Platforms | Microsoft 365, Exchange, Google Calendar, 25Live, Ad Astra |
| Third-Party App Support | Supported via Crestron-approved applications |
| RAM | 8 GB LPDDR4 |
| Storage | 40 GB eMMC |
| Ethernet | 10/100/1000 Mbps with PoE+ support |
| Wireless Connectivity | Wi-Fi 6E (2.4, 5, 6 GHz), 2x2 MIMO |
| Bluetooth | Integrated beacon support |
| USB Port | USB Type-C (host) |
| Audio | Built-in speakers |
| Video Decoding | H.264, H.265, MJPEG up to 4K30 |
| Power Requirements | PoE+ (IEEE 802.3at Type 2) |
| Operating Temperature | 32° to 104°F (0° to 40°C) |
| Humidity | 10% to 95% non-condensing |
| Mounting Options | Wall, surface, or electrical box mounting |
| Dimensions (H x W x D) | 5.96 x 9.68 x 1.18 in. |
| Weight | 1.27 lb |
| Finish | White |
