Description
The Lenovo 7DD5A00AWW is an RT11kVA 6U Rack or Tower UPS-G2 designed to provide power protection for server and IT environments. The 200–240VAC single-phase UPS uses online double-conversion topology with sinewave output and supports both rack and tower deployment.
It provides up to 11,000VA and 10,000W capacity, with efficiency up to 94.5% in online mode and up to 98% in high-efficiency mode. Hot-swappable VRLA batteries, Advanced Battery Management technology, a Maintenance Bypass module, and network management capabilities support power availability and management.
Product Highlights
- 11,000VA / up to 10,000W UPS
- 6U rack or tower form factor
- 200–240VAC single-phase input
- Online double-conversion topology
- Sinewave output
- Up to 98% high-efficiency mode
- Hot-swappable VRLA batteries
- Network management capability
Technical Specifications
| Specification | Details |
|---|---|
| Brand | Lenovo |
| Manufacturer Part Number | 7DD5A00AWW |
| Product Series | RT11kVA UPS-G2 |
| Product Type | Uninterruptible Power Supply |
| Form Factor | 6U Rack or Tower |
| Topology | Online Double Conversion |
| Waveform | Sinewave |
| VA Rating | 11,000VA |
| Maximum Power | 10,000W |
| Input Voltage | 200–240V AC, 1-Phase |
| Input Frequency | 50/60Hz |
| Maximum Input Amperage | 50A |
| Input Connector | Hardwired Terminal Block |
| Output Voltage Settings | 200/208/220/230/240V AC |
| Output Frequency | 50/60Hz |
| Output Connectors | 4x IEC 320-C19 (16A) |
| Online Efficiency | Up to 94.5% |
| High-Efficiency Mode | Up to 98% |
| Battery Type | VRLA |
| Battery Replacement | Hot-Swap |
| Energy Star Compliant | Yes |
| Feature Code | BV3E |
