Description
The Belkin Universal 2nd Gen Secure KVM Switch is engineered for high-security environments that demand strict data isolation and uncompromising performance. Designed to meet NIAP Protection Profile PSD 4.0 requirements, this 16-port single-head KVM enables operators to securely manage up to sixteen computers from a single workstation without risking data leakage between systems.
Built with advanced cybersecurity features, the switch uses dedicated processors and isolated signal paths for every port, ensuring complete separation of video, audio, and USB peripherals. Optical data diodes enforce unidirectional data flow, while integrated peripheral filtering and device authentication block unauthorized access attempts. The system also features CAC and audio freeze functionality for enhanced operational control in sensitive environments.
Supporting ultra-high-definition resolutions up to 4K at 60Hz via DisplayPort and HDMI, this secure KVM delivers exceptional visual clarity with minimal latency. Its intuitive design includes customizable port identification with color coding, improving workflow accuracy and reducing switching errors. With tamper-evident labeling, secure packaging, and active anti-tamper protection, the device ensures integrity from deployment through operation.
Ideal for government, defense, financial, and enterprise applications, the Belkin Secure KVM Switch provides robust, compliant, and reliable system control where security cannot be compromised.
| Specification | Details |
|---|---|
| Brand | Belkin |
| Product Type | Secure KVM Switch |
| Ports Supported | Supports up to 16 host computers |
| Console Support | Single monitor console |
| Maximum Resolution | Supports up to 4K (3840 x 2160) at 60Hz |
| Video Interfaces | DisplayPort and HDMI combo support |
| Audio Support | Analog audio via 3.5 mm jack with ultrasonic filtering |
| USB Support | USB keyboard and mouse with secure peripheral filtering |
| CAC Support | Includes CAC and DPP port functionality |
| Security Compliance | Designed for NIAP Protection Profile PSD 4.0 |
| Data Protection | Dedicated processors with isolated signal paths per port |
| Data Flow Protection | Optical data diodes enforce unidirectional communication |
| Peripheral Security | USB device authentication prevents unauthorized usage |
| Display Security | Protected display interface prevents data leakage |
| Anti-Tampering | Active tamper detection with holographic tamper-evident labeling |
| Switching Performance | Fast switching with no keyboard or mouse delay |
| Port Identification | Customizable port naming and color coding |
| Remote Control Compatibility | Supports optional Belkin Secure KVM Remote Control |
| Form Factor | Desktop with optional rack or under-counter mounting |
| Housing Material | Formed sheet steel construction |
| Power Supply | Internal power supply included |
| Power Rating | 12V DC, 4.0A |
| Input Voltage | 100–240V AC |
| Plug Type | IEC female with interchangeable mains connector |
| Certifications | FCC Class A, UL, CE, RoHS, ICES, RCM |
| TAA Compliance | Fully TAA compliant |
