Description
The Belkin IsoClave RED/BLACK Secure KVM Switch is purpose-built for high-security environments that demand strict isolation between classified and unclassified systems. Engineered to meet advanced cybersecurity standards, this 2-port dual-head KVM switch delivers uncompromising protection through 60dB signal isolation, ensuring complete separation between connected systems.
Designed for mission-critical applications across government, defense, finance, and healthcare sectors, this solution supports UHD 4K resolution at 60Hz and provides seamless switching between two host systems with dual display output. Preinstalled isolating USB and DisplayPort cables with tamper-resistant design eliminate deployment risks while ensuring compliance and operational integrity.
With built-in anti-tamper mechanisms, optical data diodes for secure unidirectional data flow, and blocked unauthorized ports, this KVM switch safeguards sensitive data at every level. Its intuitive port identification system and compatibility with remote control accessories further enhance operator efficiency and situational awareness.
Built in a rugged aluminum enclosure and backed by enterprise-grade support, the Belkin IsoClave Secure KVM Switch is a reliable, secure, and ready-to-deploy solution for organizations that cannot compromise on cybersecurity.
| Specification | Details |
|---|---|
| Product Type | Secure KVM Switch |
| Number of Supported Computers | 2 Systems |
| Display Support | Dual Head (2 Displays) |
| Maximum Resolution | 3840 x 2160 (UHD 4K) @ 60Hz |
| Console Ports | USB Type-A for keyboard and mouse |
| Console Display Ports | 2 x DisplayPort 1.2 |
| Computer Display Ports | 2 x DisplayPort 1.2 |
| Computer USB Ports | USB Type-B |
| Security Compliance | NIAP Protection Profile PSD 4.0 |
| Signal Isolation | 60dB Isolation Between Channels |
| Data Protection | Optical data diodes for unidirectional USB data flow |
| Anti-Tamper Protection | Always-on, battery-backed active tamper detection |
| Cable Design | Preinstalled isolating cables with tamper-resistant screws |
| Blocked Interfaces | HDMI, analog audio, and remote control ports disabled |
| Power Requirements | 12V DC, 2.5A power supply |
| Input Voltage | 100 to 240VAC |
| Operating Temperature | 0°C to 40°C |
| Storage Temperature | -20°C to 60°C |
| Humidity | 0–80% non-condensing |
| Enclosure | Heavy-duty aluminum with metal faceplate |
| Dimensions | 12.5 x 1.7 x 6.2 inches |
| Weight | 4.85 lbs |
| Compliance | FCC, UL, CE, RoHS, ICES, RCM, UKCA |
| Build & Support | Designed in California, assembled in the USA |
| Warranty | 3-Year Limited Warranty (extendable) |
