Description
The Mimo Monitors 21.5" Full HD Outdoor Touchscreen Commercial Monitor is engineered for high-performance outdoor digital signage and interactive applications. Featuring a 1500-nit high-brightness display, this unit ensures exceptional visibility even in direct sunlight, making it ideal for environments such as quick-service restaurants, gas stations, sports venues, and amusement parks.
Designed for durability and reliability, the MOD-21580CH is built with a rugged all-aluminum enclosure and is IP65-rated for protection against dust, water, and environmental contaminants. Its IK10-rated impact-resistant construction helps safeguard against vandalism, ensuring long-term operation in public-facing installations.
The integrated 10-point capacitive touchscreen delivers precise and responsive interactivity, while optical bonding and anti-glare treatment enhance clarity and reduce reflections. With support for both Windows and Linux HID systems, along with flexible portrait and landscape orientation, this display offers seamless integration into a wide range of commercial deployments. Built for continuous operation with a 24/7 duty cycle and a wide operating temperature range, it is a dependable solution for demanding outdoor conditions.
| Category | Specification |
|---|---|
| Display Size | 21.5 inches |
| Panel Type | LCD |
| Resolution | 1920 x 1080 (Full HD) |
| Aspect Ratio | 16:10 |
| Brightness | 1500 nits |
| Contrast Ratio | 1000:1 |
| Viewing Angles | 178° horizontal / 178° vertical |
| Refresh Rate | 60 Hz |
| Surface Treatment | Anti-glare with 3H hardness |
| Touch Technology | 10-point projected capacitive multi-touch |
| Operating System Support | Windows and Linux HID compatible |
| Orientation | Landscape and portrait |
| A/V Inputs | 1x HDMI, 1x VGA |
| A/V Outputs | 1x 3.5 mm audio |
| USB Ports | 1x USB-A (for touch control) |
| Ethernet | Not available |
| Ambient Light Sensor | Yes |
| Built-In Speakers | Not included |
| Built-In Microphone | Not included |
| Power Consumption | 60 W (operational) |
| Input Power | 100 to 240 VAC, 50/60 Hz |
| Power Adapter | External |
| Mounting | VESA 100 x 200 mm |
| Environmental Rating | IP65 dust and water resistance |
| Impact Protection | IK10-rated vandal resistance |
| Operating Temperature | -18°C to 60°C (-0.4°F to 140°F) |
| Duty Cycle | 24/7 continuous operation |
| Certifications | CE, FCC, RoHS |
| Enclosure Material | All-aluminum housing |
| Included Accessories | Power supply, remote control |
| Warranty | Limited 1-year manufacturer warranty |
