Description
The Advantech FPM-221W-P4AE is a rugged 21.5-inch Full HD industrial monitor designed for smart factory visualization, machine automation, and demanding industrial HMI applications. Featuring a true-flat projected capacitive (PCAP) touchscreen with 10-point multi-touch support, it delivers intuitive and responsive operation even in harsh environments.
Built with a die-cast aluminum chassis and an IP66-rated front bezel, the FPM-221W-P4AE offers excellent durability, dust protection, and water resistance. Its slim design supports flexible installation with panel mounting or VESA arm mounting, while the direct HDMI input ensures easy integration with industrial systems.
With lockable I/O connectors and reliable long-life LED backlighting, this industrial display is engineered for continuous operation in Industry 4.0 environments.
| Specification | Details |
|---|---|
| Brand | Advantech |
| Model / SKU | FPM-221W-P4AE |
| Display Size | 21.5 inch widescreen |
| Resolution | 1920 × 1080 Full HD |
| Display Type | TFT LED LCD |
| Touchscreen Type | Projected Capacitive (PCAP) |
| Multi-Touch Support | 10-point multi-touch |
| Touch Interface | USB |
| Video Input | Direct HDMI |
| Viewing Angle | 178° (H) / 178° (V) |
| Brightness | 250 cd/m² |
| Contrast Ratio | 1000:1 |
| Front Panel Protection | IP66-rated bezel |
| Enclosure Material | Die-cast aluminum chassis |
| Mounting Options | Panel mount, VESA arm |
| Power Input | External 60W adapter, DC +12V |
| Operating Temperature | 0°C to 50°C |
| Dimensions (W × H × D) | 558.4 × 349.8 × 56.2 mm |
| Net Weight | Approx. 6 kg |
