Description
The 22-inch Square Flex-OS Intel Display is a compact, high-performance digital signage solution engineered for modern commercial environments. Featuring a unique 1:1 square aspect ratio and crisp 1920x1920 resolution, this display is ideal for retail, wayfinding, menu boards, and creative content applications where non-traditional layouts stand out.
Built with Flex-OS versatility, this display supports both embedded system-on-chip (SoC) configurations and external media players via HDMI, allowing seamless switching between inputs without replacing hardware. The integrated Intel-based platform supports Windows, Linux, and ChromeOS Flex environments, enabling flexible deployment across enterprise ecosystems.
With 500-nit brightness, wide viewing angles, and 24/7 operational capability, this display delivers consistent, high-quality visuals in demanding environments. Its finished enclosure, compact footprint, and VESA mounting compatibility make it easy to deploy in a variety of installations while maintaining a clean, professional appearance.
| Specification | Details |
|---|---|
| Display Size | 22.0-inch Square LCD |
| Resolution | 1920 x 1920 |
| Aspect Ratio | 1:1 Square Format |
| Brightness | 500 nits |
| Contrast Ratio | 1000:1 |
| Viewing Angle | 89° horizontal / 89° vertical |
| Display Type | Flat LCD Panel |
| Operating Capability | Designed for continuous 24/7 operation |
| System Architecture | Intel-based embedded SoC (supports Windows, Linux x64, ChromeOS Flex) |
| External Input Support | HDMI input available for external media players |
| Touch Control | mini-USB touch screen override supported |
| Storage Expansion | 1x Micro-SD slot |
| USB Ports | 1x USB 2.0 |
| Control Interfaces | Phoenix GPIO (4-pin bi-directional), RS232 via 3.5mm jack |
| Network Connectivity | RJ45 Ethernet |
| Audio Output | 3.5mm analog/digital audio out |
| Wireless Connectivity | Optional Wi-Fi support |
| Power Requirements | 12V 4A adapter (Micro Molex connection) |
| Mounting Compatibility | VESA 200 x 200 mm (M4 x 6 mm) |
| Enclosure Type | Finished housing, non-touch |
| Product Dimensions | 16.2” x 16.2” x 1.6” |
| Flex-OS Capability | Supports internal or external media players with automatic input switching |
