Description
The Fluke Networks DSX-8000-MOD is a high-performance 2 GHz DSX CableAnalyzer Module Replacement designed to accelerate every stage of copper cabling certification. Engineered for unmatched speed and accuracy, it supports testing for Cat 6A, Cat 8, Class FA, I/II, and all current standards—delivering results in as little as 8 seconds for Cat 6A.
With the Versiv™ modular design, it integrates seamlessly into copper certification, fiber optic loss testing, OTDR testing, and fiber end-face inspection workflows. Its ProjX™ management system streamlines job setup to system acceptance, ensuring all tests are done right the first time, while the Taptive™ touchscreen interface simplifies operation for technicians of all skill levels.
The DSX-8000-MOD is fully compatible with LinkWare™ Live cloud service for remote setup, monitoring, and location tracking, and with LinkWare™ PC software for professional-grade test reports. Its advanced diagnostics quickly locate faults such as crosstalk, return loss, and shield issues, reducing troubleshooting time significantly. Built to Fluke Networks’ rugged standards, it’s the trusted choice for certifying high-performance network cabling with ANSI/TIA-1152-A Level 2G and IEC 61935-1 Ed. 5 Level VI accuracy.
| Specification | Details |
|---|---|
| Type | 2 GHz DSX CableAnalyzer Module Replacement |
| Compatibility | Versiv™ platform (copper & fiber testing) |
| Supported Cabling | Cat 5e, 6, 6A, 8, Class FA, I/II (100 Ω & 120 Ω) |
| Max Frequency | 2000 MHz |
| Autotest Speed | Cat 6A: 8 s; Cat 8: 16 s |
| Accuracy Level | ANSI/TIA-1152-A Level 2G, IEC 61935-1 Ed. 5 Level VI |
| Test Parameters | Wire Map, Length, Propagation Delay, Delay Skew, DC Loop Resistance, Insertion Loss, Return Loss, NEXT, ACR-N, ACR-F, Alien Crosstalk |
| User Interface | 5.7 in LCD with capacitive touchscreen (Taptive™) |
| Diagnostics | Crosstalk, return loss, shield faults with distance-to-fault |
| Job Management | ProjX™ system with LinkWare™ Live & LinkWare™ PC support |
| Battery | Lithium-ion, ~8 h typical use |
| Dimensions | 2.625 in × 5.25 in × 11 in (w/ module & battery) |
| Weight | 1.28 kg (3 lb, 5 oz) |
| Operating Temp. | 0 °C to 45 °C |
| Storage Temp. | –20 °C to +50 °C |
| Safety | CSA 22.2 No. 61010, IEC 61010-1 2nd Ed. + Amendments |
| Compliance | PoE (IEEE 802.3bt), Resistance Unbalance, TCL, ELTCTL |
