Description
The Infortrend JB3024RBA0-0032 is a 2U, 24-bay cloud-integrated unified storage system designed for ultra-high performance, enterprise-grade availability, and effortless cloud integration. It consolidates SAN, NAS, and object storage into a single platform, simplifying deployment and management while supporting both structured and unstructured workloads.
Built for demanding environments, this system delivers up to 740K IOPS, 11GB/s block throughput, and 3,000MB/s CIFS bandwidth. Intelligent SSD caching, automated tiering, protocol translation, and hot/cold data optimization ensure consistently high performance across applications while maximizing storage efficiency through deduplication and compression.
| Category | Specification |
|---|---|
| System Type | Cloud-integrated unified storage |
| Form Factor | 2U, 19-inch rackmount |
| Drive Bays | 24 |
| Maximum Drives | 24 per system / up to 444 via JBOD |
| Supported Drives | 2.5" SAS SSD, 2.5" SATA SSD, 2.5" 10K RPM SAS HDD |
| Drive Interface | 12Gb/s SAS |
| Controllers | Dual redundant controllers |
| Cache Memory | DDR4 8GB default; expandable up to 256GB |
| Performance | Up to 740K IOPS, 11GB/s block, 3,000MB/s CIFS |
| Storage Protocols (File) | CIFS/SMB, AFP, NFS, FTP, WebDAV |
| Storage Protocols (Block) | FC, FCoE, iSCSI, SAS |
| Storage Protocols (Object) | REST API |
| Cloud Gateway | Amazon S3, Microsoft Azure, Google Cloud Platform, Alibaba AliCloud |
| Host Connectivity (Onboard) | 1GbE iSCSI, 10GbE iSCSI |
| Host Connectivity (Optional) | FC, FCoE, iSCSI (RJ-45 / SFP+), SAS |
| RAID Support | RAID 0, 1, 5, 6, 10, 50, 60 |
| Data Services | Thin provisioning, SSD cache, automated tiering, snapshots, replication |
| Security | AES-256 encryption, SSL, SED support |
| Availability Features | Redundant hot-swappable modules, SMB 3.0 transparent failover |
| Management | Web-based EonOne management, SSH/Telnet monitoring |
| Network Features | IPv6, link aggregation (802.3ad), MPIO, Jumbo Frames |
| OS Compatibility | Windows Server, Linux, VMware, Citrix, macOS, UNIX variants |
| Power Supplies | Dual 530W, 80 PLUS certified |
| Input Voltage | 100–240 VAC, auto-switching |
| Operating Temperature | 0–40°C (0–35°C with BBU/CBM) |
| Relative Humidity | 5–95% non-condensing |
