Description
The Wisenet PRN-3200B2 32-Channel 8K AI NVR (80TB) delivers high-performance recording, advanced analytics, and flexible storage for large-scale surveillance environments. Supporting up to 32 network cameras and resolutions up to 32MP, this NVR is engineered for enterprise-grade security deployments requiring reliability, intelligence, and high-bandwidth processing.
Equipped with AI search tools—including BestShot, attribute-based filtering, object/vehicle/face detection, and license plate recognition—this NVR significantly reduces investigation time when paired with Wisenet AI cameras. Its 400Mbps recording throughput, dual-display 4K/1080p output, fisheye dewarping, Dynamic Event support, and WiseStream compression ensure smooth operation and optimized bandwidth usage.
With eight internal SATA bays supporting up to 80TB of storage, RAID 5/6 protection, ARB (Automatic Recovery Backup), and mobile access via QR-code pairing, the PRN-3200B2 offers a robust and scalable video management platform for demanding security applications.
| Category | Details |
|---|---|
| SKU | PRN-3200B2-80TB |
| Channels | Up to 32 network camera inputs |
| Max Resolution | Up to 32MP (8K) |
| Video Codecs | H.265, H.264, MJPEG, WiseStream |
| AI Features | BestShot, attribute search, human/face/vehicle detection, license plate recognition (Wisenet AI cameras only) |
| Recording Bandwidth | Up to 400 Mbps |
| Playback Bandwidth | RAID: 64 Mbps; Non-RAID: 32 Mbps |
| Recording Modes | Normal, Dual Stream, Schedule, Event (Pre/Post), Bookmark |
| Storage Capacity | 8 × SATA HDDs (up to 80TB total, up to 10TB each) |
| RAID Support | RAID 5 / RAID 6 |
| External Storage | iSCSI |
| Display Output | HDMI 1: 3840×2160 (30Hz); HDMI 2: 1920×1080 (60Hz) |
| Multi-Screen Options | Dynamic layout; clone mode up to 36 divisions; expand mode up to 36 divisions |
| Playback Simultaneous | Up to 80 channels |
| Fisheye Dewarping | Supported (Local 1CH, CMS) |
| Network Protocols | IPv4/IPv6, TCP/IP, UDP, RTP/RTSP, HTTP/HTTPS, DHCP, NTP, DDNS, ONVIF, SUNAPI |
| Max Remote Users | Search: 3 |
| Audio | 32CH network audio; G.711, G.726, AAC; 2-way audio |
| Interface Ports | 3 × RJ-45 (1GbE), 2 × HDMI, 4 × USB (2×USB2.0 + 2×USB3.0), 8 alarm-in, 4 alarm-out, audio out |
| Power Requirements | 100–240VAC, 50/60Hz, max 205W (with 8×10TB HDD) |
| Operating Temperature | 0°C to +40°C (32°F to 104°F) |
| Operating Humidity | 20% to 85% RH |
| Dimensions | 438.0 × 86.0 × 434.9 mm (17.47 × 3.39 × 17.12 in) |
| Weight | Approx. 9.1 kg (20.1 lb), HDD not included |
| Mobile Support | iOS, Android; QR-code P2P setup |
| Additional Features | ARB (Automatic Recovery Backup), Failover N+1, Dynamic Event, Smart Search, bookmark management |
