Description
The Belkin IsoClave RED/BLACK Secure KVM Switch is purpose-built for high-security environments requiring strict isolation between classified and unclassified systems. This 4-port dual-head model enables seamless control of up to four computers using dual displays while maintaining uncompromising protection against data leakage and cyber threats.
Engineered to meet advanced cybersecurity standards, this Secure KVM features true physical isolation with 60dB signal separation between red and black channels, ensuring secure operation across sensitive networks. Preinstalled, tamper-resistant USB and DisplayPort cables eliminate unauthorized connections while simplifying deployment. Blocked peripheral ports and unidirectional data flow further enhance system integrity.
With support for UHD 4K resolution at 60Hz, the switch delivers exceptional visual performance alongside mission-critical security. Customizable port identification and intuitive front-panel controls improve operator awareness and reduce switching errors in demanding environments such as government, defense, finance, and healthcare.
Built with a rugged aluminum enclosure and backed by enterprise-grade support, the Belkin IsoClave Secure KVM provides a reliable, compliant, and ready-to-deploy solution for secure workstation management.
| Specification | Details |
|---|---|
| Product Type | Secure KVM Switch |
| Model | IsoClave RED/BLACK Series |
| Ports Supported | 4 Computers |
| Display Support | Dual Head (2 Displays) |
| Maximum Resolution | Up to 3840 x 2160 (4K UHD) at 60Hz |
| Video Interface | DisplayPort 1.2 |
| Console Ports | USB Type-A for keyboard and mouse |
| Computer Interface | USB Type-B for keyboard and mouse |
| Security Features | 60dB signal isolation, port isolation, unidirectional data flow, blocked peripheral ports |
| Cable Design | Preinstalled USB and DisplayPort cables with tamper-resistant screws |
| Compliance Standards | NIAP Protection Profile PSD 4.0, TEMPEST isolation requirements, TAA compliant |
| Anti-Tamper Protection | Active, always-on, battery-backed tamper detection system |
| Build Material | Heavy-duty aluminum enclosure |
| Power Requirements | 12V DC power supply, 100–240V AC input |
| Operating Temperature | 0°C to 40°C |
| Storage Temperature | -20°C to 60°C |
| Humidity | 0–80% non-condensing |
| Dimensions | 317.5 x 91.4 x 162.6 mm |
| Weight | Approx. 2.2 kg |
| Warranty | 3-year limited warranty (extendable options available) |
| Use Case | Government, military, finance, healthcare, and secure enterprise environments |
