Description
The iPGARD SAHDN-4S-P is a high-assurance 4-port secure KVM switch engineered for mission-critical environments that demand uncompromising data isolation and operational integrity. Designed for government, defense, and enterprise security applications, this single-head DisplayPort/HDMI KVM enables seamless control of up to four systems while ensuring complete separation of data channels.
Built with advanced security architecture, the SAHDN-4S-P prevents data leakage through strict peripheral isolation, secure channel switching, and tamper-evident protections. The configurable CAC port enhances authentication workflows, allowing authorized devices such as smart card or biometric readers to integrate securely into operations.
Supporting up to 4K Ultra-HD resolution at 60Hz, this KVM delivers high-performance video clarity without sacrificing security. USB keyboard and mouse emulation ensures continuous system recognition, enabling fast switching without exposing systems to unauthorized peripherals. With no wireless connectivity, no data storage, and no external interface vulnerabilities, this solution is ideal for environments where compliance and security are paramount.
| Specification | Details |
|---|---|
| Device Type | Secure 4-Port Single-Head DP/HDMI KVM Switch |
| Video Format | DisplayPort 1.2a and HDMI 2.0 |
| Video Inputs | 4 DisplayPort and 4 HDMI inputs |
| Video Outputs | 1 DisplayPort and 1 HDMI output |
| Maximum Resolution | Supports up to 3840 × 2160 at 60Hz (4K Ultra-HD) |
| USB Inputs | 8 USB Type-B connections |
| USB Outputs | 2 USB 1.1 Type-A ports for keyboard and mouse |
| CAC Support | Configurable USB 2.0 CAC port for authentication devices |
| Audio Input | 4 × 3.5mm stereo audio inputs |
| Audio Output | 1 × 3.5mm stereo audio output |
| Switching Method | Front panel tactile buttons with LED indicators |
| Security Features | Data isolation, no data storage, no hotkeys, anti-tamper protection, peripheral filtering |
| Emulation | USB keyboard and mouse emulation for continuous connectivity |
| Cable Length Support | Up to 20 ft for input and output connections |
| Power Supply | External adapter, 100–240 VAC to 12VDC, 24W |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Storage Temperature | -20°C to 60°C (-4°F to 140°F) |
| Humidity | Up to 80% non-condensing |
| Dimensions | 12.6 in (W) × 1.76 in (H) × 6.69 in (D) |
| Weight | 4.2 lbs |
| Certifications | NIAP PP 4.0 compliant, UL, CE, RoHS, FCC Class A |
| Operating Systems | Compatible with Windows, macOS, and Linux |
| Use Cases | Government, defense, secure control rooms, finance, healthcare, data centers |
