Description
The Opengear CM8148-10G Console Server is built for high-density IT environments requiring resilient out-of-band management. Featuring 48 serial ports, 10G SFP+ uplinks, and advanced automation, it ensures secure, continuous remote access to your network infrastructure.
Powered by a dual-core Marvell CPU, with 2 GB DDR4 RAM and 32 GB flash memory, the CM8148-10G delivers reliability and performance at scale. Enterprise-grade security is built-in with TPM 2.0, AAA authentication, firewall protection, and VPN support.
Designed for efficiency, the 1U rack-mountable chassis reduces cabling complexity and operational overhead, while redundant power supplies provide resiliency. With proactive alerting, temperature sensors, and Smart Out-of-Band™ capabilities, administrators gain robust visibility and control even during primary network outages.
Includes rack-mount kit, DB-9 to RJ-45 adapter, patch cable, and dual power cables (US). Backed by a 4-year warranty and technical support, the CM8148-10G is the trusted choice for enterprise and data center deployments.
| Category | Details |
|---|---|
| Brand | Opengear |
| Product Line | CM8100 Series |
| Model | CM8148-10G |
| Manufacturer Part # | CM8148-10G-US |
| Product Type | Console Server |
| Form Factor | 1U Rack-Mountable |
| Processor | Marvell 88F6820, Dual-Core, 1.6 GHz |
| Memory | 2 GB DDR4 SDRAM |
| Flash Storage | 32 GB |
| Ports | 48 x RS-232 RJ-45, 2 x 1000Base-T RJ-45, 2 x 10GbE SFP+, 2 x USB 3.0 |
| Connectivity | Ethernet, Fast Ethernet, Gigabit Ethernet, RS-232 |
| Protocols & Features | IPSec, IPv6, OpenVPN, AAA, Firewall, VPN Support, Smart Out-of-Band™, TPM 2.0 |
| Remote Management | HTTP, SSH, SNMP, IPv6 |
| Power | Dual redundant power supplies, 25W operational consumption, AC 100–240V |
| Environmental | Operating Temp: 41–122°F (5–50°C); Humidity: 5–90% non-condensing |
| Reliability | MTBF: 150,000 Hours |
| Dimensions (W x D x H) | 17.3" x 10.4" x 1.7" (1U) |
| Weight | 7.72 lbs |
| Color | Black / Red |
| Compliance | FCC Part 15 Class A, RoHS, CE, VCCI, IEC 62368, TAA Compliant |
| Included Accessories | Rack-mount kit, 2 x power cables (US), 1 x DB-9 to RJ-45 adapter, 1 x patch cable (6 ft), mounting ears, screws, nuts |
| Warranty & Support | 4-Year Limited Warranty and Technical Support |
