Description
The Kramer 675R/T is a high-performance HDMI extender kit designed for ultra-long-distance 4K60 (4:4:4) signal transmission over multimode or single-mode fiber optic infrastructure. Engineered for mission-critical AV applications, the 675R/T converts HDMI to optical signals using Kramer certified 10Gbps SFP+ modules, ensuring near-zero latency and uncompromised image quality across distances up to 3km (MM) or 33km (SM).
Featuring I-EDIDPro™ Intelligent EDID Processing, the kit guarantees seamless plug-and-play operation between source and display devices. Its rugged, fanless DigiTOOLS® enclosure enables easy rack mounting and reliable performance in professional AV environments. With HDCP 2.2 support, advanced audio formats, and LED indicators for fast diagnostics, the 675R/T delivers a cost-effective, dependable extension solution for modern 4K installations.
| Category | Details |
|---|---|
| Inputs | HDMI (female), Fiber Optic on LC connector(s) |
| Outputs | HDMI (female), Fiber Optic on LC connector(s) |
| Ports | Micro-USB (service) |
| Max Video Bandwidth | 18Gbps |
| Max Resolution | 4096×2160 @ 60Hz, 4K60 4:4:4 |
| Latency | ≤10µsec (virtually zero) |
| Compliance | HDMI 2.0, HDCP 2.2 |
| Optical Extension | MM or SM fiber; 10Gbps SFP+ IEEE 802.3ae modules (MM included) |
| Max Reach | MM: up to 3km (OM3) • SM: up to 33km (OS1) |
| Status Indicators | Source detect, sink detect, optical link, power LEDs |
| Power Consumption | 675T: 280mA • 675R: 220mA • 12V DC, 2A source |
| Operating Temperature | 0°C to +40°C (32°F to 104°F) |
| Storage Temperature | –40°C to +70°C (–40°F to 158°F) |
| Humidity | 10%–90% non-condensing |
| Enclosure | Aluminum, convection-cooled |
| Included Accessories | 2× MM SFP+ modules, 2× power adapters, 2× mounting bracket sets |
| Product Dimensions (W×D×H) | 12.00 × 7.15 × 2.44 cm (4.72" × 2.81" × 0.96") |
| Product Weight | 0.5 kg (1.0 lb) |
| Shipping Dimensions | 15.70 × 12.00 × 8.70 cm |
| Shipping Weight | 0.7 kg (1.6 lb) |
