Description
The SmartAVI SM-EDPN-8D-S is a high-performance dual-head DisplayPort KVM switch engineered for mission-critical environments that demand flawless multi-system control and uncompromised video quality. Supporting ultra-high-definition 4K resolution at 60Hz, this 8-port KVM enables seamless switching between multiple computers while maintaining stable display configurations through advanced EDID (AUX) emulation.
Designed for control rooms, broadcast operations, digital signage, and enterprise IT environments, this solution ensures consistent screen resolution, preserved window layouts, and uninterrupted workflows when switching sources. Independent switching of USB peripherals and audio allows operators to work across systems with unmatched flexibility. With support for USB 2.0 devices, stereo audio, RS-232 control, and hotkey switching, the SM-EDPN-8D-S delivers reliable, scalable performance for complex multi-computer setups.
| Category | Specification |
|---|---|
| Video Format | DisplayPort |
| Video Resolution | Up to 3840 x 2160 @ 60Hz |
| Video Input Ports | 16 DisplayPort (dual-head across 8 systems) |
| Video Output Ports | 4 DisplayPort (dual-head console) |
| Color Depth | 24-bit |
| EDID Management | Advanced EDID (AUX) Emulation for stable display configurations |
| USB Support | USB 2.0, 1.1, and 1.0 with internal hub |
| USB Inputs | 8 USB Type B |
| USB Outputs | 2 USB 1.1 (keyboard/mouse), 2 USB 2.0 (transparent peripherals) |
| Audio Support | Stereo audio via 3.5mm connections |
| Audio Inputs | 8 x 3.5mm |
| Audio Outputs | 1 x 3.5mm |
| Control Methods | Front panel buttons, hotkeys, RS-232 |
| Switching Features | Independent switching of KVM, USB, and audio |
| Firmware | Flash upgradeable |
| Operating Systems | Compatible with Windows, Mac, Linux, Unix, DOS, and more |
| Power Supply | External adapter (100–240VAC to 12VDC) |
| Power Consumption | 24W |
| Dimensions | 17" W x 3.8" H x 6.69" D |
| Weight | 4.2 lbs |
| Operating Temperature | 0°C to 40°C |
| Storage Temperature | -20°C to 60°C |
| Humidity | Up to 80% non-condensing |
| Compliance | UL, CE, RoHS |
| Emulation | Video, keyboard, and mouse emulation |
