Description
The Samsung Flip WM55FX is a 55-inch 4K UHD interactive whiteboard display designed for modern meeting rooms, classrooms, collaboration spaces, and enterprise environments. With instant writing, smooth touch response, and intuitive access to key tools, it helps teams capture ideas, annotate content, and collaborate more naturally during presentations and brainstorming sessions.
Built with IR touch technology, a passive magnetic pen, Samsung Knox security, built-in speakers, Wi-Fi and Bluetooth connectivity, and flexible landscape or portrait orientation, the WM55FX delivers a reliable and engaging collaboration experience. Its rotatable design, anti-glare protective glass, and Tizen-powered platform make it a versatile solution for professional workspaces that need secure, interactive, and easy-to-use display technology.
| Specification | Details |
|---|---|
| Brand | Samsung |
| Product Series | Samsung Flip WMFX Series |
| Display Size | 55-inch |
| Display Type | New Edge, 60Hz |
| Resolution | 3840 x 2160 4K UHD |
| Orientation | Landscape and Portrait |
| Brightness | 450 cd/m² without glass |
| Contrast Ratio | 4000:1 without glass |
| Panel Type | VA |
| Viewing Angle | 178° horizontal / 178° vertical |
| Operating Hours | Designed for 12 hours per day, 7 days per week operation |
| Touch Technology | Infrared touch |
| Touch Points | Supports 20-touch input for internal and external touch use |
| Whiteboard Drawing Support | Whiteboard app supports up to 4 drawing inputs |
| Touch Response Time | 6.7 ms |
| Drawing Latency | 26 ms |
| Pen Type | Passive magnetic pen |
| Object Recognition | 2 mm, 4 mm, 8 mm, and 50 mm recognition with dynamic brush mode |
| Protective Glass | Heat semi-strengthened protection glass |
| Glass Thickness | 3.0T |
| Surface Treatment | Anti-glare, anti-fog, protection, and anti-microbial coating |
| Built-In Speakers | 15W x 2 channel speakers |
| Core Apps | Whiteboard, Brush, NoteOn, Document Viewer, Image Viewer, Web Browser, SmartView+, Video Player, and Workspace |
| Workspace Support | RDP, VNC, and Microsoft 365 support |
| WebRTC Support | Supported |
| SmartView+ | Supported |
| Platform | Tizen 9.0 |
| Processor | CA76 Quad Core 1.7GHz |
| Memory | 8GB |
| Storage | 64GB total, with approximately 54GB available |
| HDMI Input | 1 HDMI input on basic configuration, with additional tray-based HDMI support |
| USB-C Input | Supported with tray configuration |
| USB Connectivity | USB input with external USB in/out pair support |
| HDMI Output | 1 HDMI output |
| Audio Output | 1 stereo mini jack |
| Touch Output | USB upstream touch output support |
| Wireless Connectivity | Wi-Fi and Bluetooth support for keyboard, mouse, and speaker connectivity |
| External Control | Touch input, RS232C through stereo jack, and RJ45 for MDC |
| Security | Samsung Knox, 802.1x WPA2 Enterprise, and WPA3-Personal support |
| Power Supply | AC 100-240V, 50/60Hz |
| Maximum Power Consumption | 154W |
| Typical Power Consumption | 98W |
| Rated Power Consumption | 140W |
| Standby Power Consumption | 0.5W |
| Dimensions | 1297.4 x 768.2 x 59.9 mm |
| Package Dimensions | 1464 x 915 x 190 mm |
| Product Weight | 28.6 kg |
| Package Weight | 35.9 kg |
| VESA Mount | 400 x 400 mm |
| Bezel Color | Gray White |
| Operating Temperature | 0°C to 40°C |
| Operating Humidity | 10% to 80%, non-condensing |
| Certifications | Safety 60950-1/62368-1, EMC Class A, ENERGY STAR 8.0, EPEAT Silver |
| Included Accessories | Power cord, USB upstream cable, two gray white pens, warranty, and quick setup guide |
| Optional Stand | STN-WM55R |
| Optional Mount | WMN-4277SF |
| Optional Tray | CY-TF65BFC |
