Description
The DynaScan DS652LR5 is a 65-inch professional ultra-high brightness LCD display designed for 24/7 digital signage applications. With a sunlight-readable brightness rating of 4,000 nits, this display ensures vibrant, crystal-clear images in even the brightest environments.
Equipped with local dimming LED backlight technology, the DS652LR5 delivers superior contrast, deep blacks, and reduced power consumption. An intelligent thermal management system ensures quiet and reliable operation around the clock, making it ideal for storefronts, transportation hubs, outdoor enclosures, and video wall installations.
Designed for versatility, the DS652LR5 supports both landscape and portrait orientations, advanced daisy chaining, and professional scheduling features. Built with durability and performance in mind, this display is engineered to maintain image uniformity and withstand continuous commercial use.
| Category | Specification |
|---|---|
| Manufacturer | DynaScan Technology, Inc. |
| Series / Model | DS² / DS652LR5 |
| Display Type | LED-backlit LCD, IPS |
| Screen Size | 65" (64.53" viewable) |
| Resolution | Full HD 1920 × 1080 (1080p) |
| Brightness | 4000 cd/m² (nits) |
| Contrast Ratio | 3000:1 (static), 1,000,000:1 (dynamic) |
| Aspect Ratio | 16:9 |
| Response Time | 10 ms |
| Viewing Angle | 178° (H) / 178° (V) |
| Backlight Life | 50,000 hours |
| Video Wall Support | Up to 225 screens |
| Inputs/Outputs | DVI-D (in/out), DisplayPort, Audio In/Out, LAN, Serial (in/out) |
| Sensors | Ambient light sensor, Temperature sensor |
| Orientation Modes | Portrait / Landscape |
| Commercial Features | SNMP support, Scheduler, Daisy Chain, Blackening Defect Free |
| Mounting Options | 400 × 400 mm, 600 × 400 mm VESA |
| Dimensions (W×H×D) | 57.4 × 33.2 × 4 in (without stand) |
| Weight | 115.74 lbs (net), 124.56 lbs (shipping) |
| Power Consumption | 510 W (operational), 1 W (standby) |
| Voltage | AC 120/230 V, 50/60 Hz |
| Operating Temp. | 32 °F – 113 °F |
| Operating Humidity | 10 – 80% (non-condensing) |
| Enclosure Color | Black |
| Compliance | FCC, RoHS |
| Included Accessories | DVI cable, Serial cable, Network cable, Remote control |
