Description
The Belkin DisplayPort DuoClave Secure KVM Switch (F1DN108MKVMDC-4) is a high-security, dual-head KVM solution engineered for mission-critical environments that demand simultaneous access to multiple secure networks. Designed to support up to eight computers and two independent displays, this advanced KVM enables operators to view and manage two separate networks at the same time without compromising data integrity or security.
Built to meet NIAP Protection Profile PSD 4.0 standards, this DuoClave model ensures strict data isolation between systems. It features optical data diodes for unidirectional data flow, preventing data leakage across networks. With integrated Common Access Card (CAC) support, users can securely authenticate across multiple systems using a single reader, while CAC freeze functionality allows authentication to remain locked on one channel during multitasking.
The intuitive Key Press Seamless Cursor Switching (KPSCS) technology enhances workflow efficiency by allowing users to transition control between systems simply by moving the cursor across displays while holding a key. Combined with customizable port illumination and naming, this system improves situational awareness and reduces operator error.
Designed for durability and security, the unit features a rugged steel enclosure with an active anti-tamper mechanism that renders the device inoperable if compromised. Ideal for defense, intelligence, financial, and critical infrastructure environments, this secure KVM delivers reliable, real-time switching with uncompromised protection.
| Specification | Details |
|---|---|
| Model | F1DN108MKVMDC-4 |
| Product Type | Secure KVM Switch (DuoClave) |
| Number of Computers Supported | 8 |
| Number of Displays Supported | Up to 2 (Dual Head) |
| Video Interface | DisplayPort |
| Maximum Resolution | 3840 x 2160 @ 60Hz (4K UHD) |
| CAC Support | Yes (Shared CAC with freeze functionality) |
| Switching Method | Front panel buttons, remote control (optional), KPSCS cursor switching |
| Keyboard/Mouse Ports | USB Type-A (dedicated ports) |
| Computer Ports | USB Type-B, DisplayPort |
| Audio Support | Digital audio via DisplayPort |
| Remote Control Port | RJ14 |
| Data Protection | Optical data diodes for unidirectional data flow |
| Security Compliance | NIAP Protection Profile PSD 4.0 |
| Additional Certifications | FCC, CE, UL, ICES, RCM, RoHS, UKCA |
| Enclosure | Formed steel, tamper-resistant |
| Anti-Tamper Protection | Active, battery-backed self-destruct mechanism |
| Port Identification | Multi-color customizable LED indicators |
| Power Requirements | 12V DC, 4.0A |
| Operating Temperature | 0°C to 40°C |
| Storage Temperature | -20°C to 60°C |
| Humidity | 0–80% non-condensing |
| Mounting Options | Rackmount compatible |
| Warranty | 3 years standard (extendable) |
| Compliance | TAA compliant |
| Country of Assembly | USA |
