Description
The Belkin Universal 2nd Generation Secure KVM Switch is purpose-built for high-security environments that require strict data isolation across multiple systems. Supporting up to eight computers with dual-head DisplayPort and HDMI connectivity, this solution enables seamless switching while preventing unauthorized data transfer between networks of varying classification levels.
Engineered to meet NIAP Protection Profile PSD 4.0 requirements, this secure KVM incorporates advanced hardware-enforced isolation, unidirectional data flow, and always-on anti-tamper protection. The integrated Common Access Card (CAC) support allows secure authentication management without compromising system integrity.
With support for ultra-high-definition 4K resolution at 60Hz, USB HID device filtering, and robust metal enclosure design, this KVM switch delivers both enterprise-grade security and high-performance usability. Ideal for government, defense, and regulated enterprise environments, it ensures reliable, compliant, and efficient multi-system control from a single workstation.
| Specification | Details |
|---|---|
| Brand | Belkin |
| Model | Universal 2nd Gen Secure KVM Switch |
| SKU | F1DN208KVM-UN4W |
| Number of Ports | 8-Port |
| Display Support | Dual Head (2 Monitors per Computer) |
| Video Interfaces | DisplayPort 1.2 and HDMI 2.0 (combo ports) |
| Maximum Resolution | Up to 4K UHD (3840 x 2160) at 60Hz |
| Security Compliance | NIAP Protection Profile PSD 4.0 |
| CAC Support | Yes (Common Access Card reader support) |
| USB Support | USB keyboard and mouse (HID only, filtered devices) |
| Audio Support | 3.5mm audio output switching |
| Data Isolation | Hardware-enforced unidirectional data flow |
| Anti-Tamper Protection | Always-on active anti-tamper system |
| Peripheral Isolation | Complete separation between connected systems |
| Channel Switching | Front panel push-button selection |
| LED Indicators | Active channel, status indicators |
| Power Requirements | 100–240 VAC, 50/60Hz |
| Enclosure | Secure metal enclosure with tamper-evident labeling |
| Operating Temperature | 0°C to 40°C |
| Mounting Options | Desktop or rack-mount installation |
| Operating Systems | Windows, macOS, Linux |
| Warranty | 3-Year Limited Warranty |
