Description
The iPGARD SA-DPN-8D is an advanced 8-port dual-head secure DisplayPort KVM switch designed for high-security environments that demand strict data isolation and reliable multi-system control. Built to meet stringent security standards, this solution enables operators to seamlessly switch between up to eight computers while maintaining complete separation of data paths.
Supporting dual-monitor configurations with ultra-high-definition resolution up to 3840 x 2160 at 60Hz, the SA-DPN-8D ensures crystal-clear visuals for mission-critical applications. Integrated audio switching enhances usability, while USB support is strictly limited to keyboard and mouse to prevent unauthorized data transfer.
With automatic EDID learning, robust signal integrity, and front-panel controls for intuitive operation, this secure KVM is ideal for government, defense, healthcare, and enterprise environments where performance and security cannot be compromised.
| Specification | Details |
|---|---|
| Product Type | Secure Dual-Head DisplayPort KVM Switch |
| Number of Ports | 8-Port |
| Video Interface (Host) | 16 x DisplayPort 20-pin female |
| Console Video Output | 2 x DisplayPort 20-pin female |
| Maximum Resolution | 3840 x 2160 @ 60Hz |
| Video Compliance | DDC 5V (TTL), automatic input equalization |
| Input Cable Length | Supports up to 20 ft |
| Output Cable Length | Supports up to 20 ft |
| USB Support | Keyboard and mouse only (USB 1.1 / 1.0) |
| USB Connectors (Host) | 8 x USB Type-B |
| USB Console Ports | 2 x USB Type-A for keyboard and mouse |
| Audio Input | 8 x 3.5 mm stereo female connectors |
| Audio Output | 1 x 3.5 mm stereo female connector |
| Switching Method | Front-panel push buttons |
| Emulation | Keyboard, mouse, and video emulation |
| Power Supply | 12V DC, 3A adapter (center-positive) |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
| Storage Temperature | -4°F to 140°F (-20°C to 60°C) |
| Humidity | 0–80% non-condensing |
| Security Certification | Common Criteria validated, NIAP Protection Profile PSS Ver. 4.0 |
| Display Configuration | Dual-head (supports two monitors) |
| EDID Management | Automatic EDID learning on startup |
| Build | Designed for high-security environments |
