Description
The iPGARD SDVN-8S-P-LM is a high-security 8-port single-head DVI-I KVM switch engineered for mission-critical environments where absolute data isolation and system integrity are required. Designed to meet stringent security standards, this Secure Pro KVM enables users to control up to eight computers while preventing any data leakage between connected systems.
Built with advanced keyboard and mouse USB emulation, the switch maintains continuous communication with all connected systems, enabling seamless and ultra-fast switching without exposing endpoints to unauthorized peripheral detection. The integrated configurable CAC (Common Access Card) port allows secure authentication device sharing under controlled conditions, enhancing operational efficiency without compromising security.
With non-reprogrammable ROM, active anti-tamper protection, and secure EDID learning, the SDVN-8S-P-LM ensures that sensitive environments such as government, defense, finance, and healthcare operations remain protected against cyber threats. Its support for high-resolution DVI-I video up to 2560x1600 ensures uncompromised visual performance alongside enterprise-grade security.
| Specification | Details |
|---|---|
| Number of Ports | 8-Port KVM |
| Display Type | Single-Head DVI-I |
| Maximum Resolution | Up to 2560 x 1600 @ 60Hz |
| Video Interface | DVI-I (Dual Link, DVI 1.0 compatible) |
| USB Support | USB 1.1 and USB 2.0 compatible |
| Keyboard & Mouse Emulation | Dedicated USB emulation for secure switching |
| CAC Support | Configurable USB 2.0 CAC port |
| Audio Support | 3.5mm stereo audio input and output |
| Data Isolation | Absolute isolation between all ports |
| Security Features | Non-reprogrammable ROM, anti-tamper switches, tamper-evident seals |
| Certification | NIAP PP 3.0 compliant |
| Switching Method | Front panel tactile buttons with LED indicators |
| Operating Systems | Compatible with Windows, macOS, and Linux |
| Power Supply | External 100–240VAC, 12VDC 3A |
| Power Consumption | 36W |
| Dimensions | 17.0” W x 1.76” H x 8.69” D |
| Weight | 6.3 lbs |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Storage Temperature | -20°C to 60°C (-4°F to 140°F) |
| Humidity | Up to 80% non-condensing |
