Description
The Kramer VP-778 is a highly versatile 8-input presentation matrix switcher and scaler designed for professional AV environments requiring seamless video switching, picture-in-picture functionality, and flexible output configurations. Engineered with advanced PixPerfect™ scaling and K-IIT XL™ image-insertion technology, the VP-778 delivers ultra-smooth transitions, stable PiP overlays, and exceptional visual performance.
This powerful unit can operate as a single 4K@30Hz output scaler or as a dual-output HD scaler system, enabling independent content routing to two HDMI outputs—each mirroring to a corresponding HDBaseT output for extended-distance transmission. With support for HDMI, DVI-U, and HDBaseT inputs, plus robust audio capabilities including microphone inputs, balanced audio, S/PDIF, and a built-in 2x10W amplifier, the VP-778 is ideal for auditoriums, conference rooms, classrooms, and broadcast setups.
Control is flexible and intuitive through front-panel buttons, integrated web pages, RS-232, Ethernet, and IR control. With advanced EDID management, test patterns, auto-switching, and extensive audio DSP, the VP-778 ensures reliable, professional-grade performance in any 24/7 AV installation.
| Category | Details |
|---|---|
| Inputs | 4 HDMI (deep color); 2 DVI-U (DVI/HDMI/PC/YPbPr/CV); 2 HDBaseT on RJ-45; 4 HDMI, 2 DVI-U & 2 HDBaseT via 3.5mm mini-jacks; 2 Mic (6mm jack, unbalanced, selectable 48V phantom power) |
| Outputs | 2 HDMI (deep color); 2 HDBaseT on RJ-45; 1 S/PDIF digital audio (RCA); 1 balanced stereo (5-pin terminal block); 1 stereo speaker output 2×10W @ 8Ω (4-pin terminal block) |
| Video Features | PixPerfect™ scaling; K-IIT XL™ PiP technology; seamless switching (cut/fade); dual scalers; luma/chroma keying; multiple aspect ratios; advanced de-interlacing; built-in test patterns |
| Output Resolutions | Up to 4K@30Hz UHD (3840×2160); extensive PC & HDTV resolutions from 640×480 to 2048×1080 and 1080p/4K formats |
| HDBaseT Range | Up to 130m (430ft) normal mode; up to 180m (590ft) ultra mode (1080p@60Hz@24bpp with BC-UNIKAT cables) |
| Audio Features | Balanced stereo inputs; dual mic inputs; digital & balanced stereo outputs; audio DSP; AFV & breakaway; built-in proc-amp; talkover or mix modes |
| Controls | Front panel, OSD, IR, Ethernet web UI, 2× RS-232, RS-485 |
| Power | 100–240V AC; 50VA max |
| Environmental | Operating: 0°C to +40°C; Storage: −40°C to +70°C; Humidity: 10–90% non-condensing |
| Dimensions (W × D × H) | 19" × 9.34" × 1U (43.6cm × 23.72cm × 4.36cm) |
| Weight | Product: 2.6kg (5.7lbs); Shipping: 3.8kg (8.4lbs) |
