Description
The Kramer VP-778/110V is a high-performance 8-input presentation matrix switcher and scaler designed for professional installations requiring seamless switching, picture-in-picture (PiP), and flexible 4K output options. Engineered for corporate boardrooms, lecture halls, hospitality environments, and multi-display setups, it delivers exceptional image quality with PixPerfect™ scaling, K-IIT XL™ PiP technology, and smooth, zero-glitch transitions.
This versatile switcher/scaler supports up to 4K30 UHD in single-window mode and can operate as dual independent scalers, allowing two unique HDMI outputs—each mirrored to HDBaseT—for extended-distance transmission. It also integrates powerful audio capabilities, including analog and embedded audio, a built-in 2x10W amplifier, microphone inputs with phantom power, DSP audio processing, and selectable talkover/mix modes.
With advanced control options such as RS-232, Ethernet web interface, IR, and front-panel operation, the VP-778/110V is built for reliability, flexibility, and smooth professional AV workflows.
| Category | Details |
|---|---|
| Inputs | 4 HDMI; 2 DVI-U (DVI/HDMI/PC/YPbPr/CV); 2 HDBaseT on RJ-45; 2 mic inputs (6mm, selectable 48V phantom power) |
| Outputs | 2 HDMI; 2 HDBaseT; 1 S/PDIF (RCA); 1 balanced stereo audio (5-pin TB); 1 stereo speaker output (2x10W @ 8Ω) |
| Video Features | Seamless switching; PiP/PaP; 4K@30Hz output; multiple aspect ratios; advanced de-interlacing; HDMI Deep Color; EDID management; test patterns |
| Audio Features | Balanced stereo inputs; analog & embedded audio; DSP processing; microphone talkover/mix; audio-follow-video; breakaway audio |
| Scaling | PixPerfect™ scaling; dual independent scalers; customizable main & PiP windows |
| Control Options | Front panel, OSD, IR remote, Ethernet/web control, RS-232 (x2), RS-485 |
| HDBaseT Performance | Up to 130m (430 ft); up to 180m (590 ft) in Ultra Mode @1080p60 |
| Output Resolutions | Up to 4K30 UHD; includes 480i/p, 576i/p, 720p, 1080p, WUXGA, 2048x1080 |
| Power Requirement | 100–240V AC, 50VA max |
| Operating Temperature | 0° to +40°C (32° to 104°F) |
| Dimensions | 19" x 9.34" x 1U (43.6cm x 23.72cm x 4.36cm) |
| Weight | Approx. 2.6kg (5.7 lbs) |
