Description
The Hanwha Techwin XRN-1620SB1 is a high-performance 16-channel Network Video Recorder engineered for professional surveillance environments requiring reliable 4K monitoring, powerful recording performance, and simplified deployment. Equipped with a 4 TB pre-installed HDD, this NVR supports up to 24 TB of total storage and integrates 16 built-in PoE ports, enabling direct camera power and significantly reducing installation time and cost.
Designed for advanced usability, the XRN-1620SB1 features timeline preview, allowing users to hover over the timeline to instantly view image snapshots for faster search and review. The system also provides centralized event and alarm configuration, making multi-channel management easy and efficient.
Live monitoring is enhanced with real-time channel information, digital PTZ control, and a highly intuitive interface. Support for up to 100 bookmarks ensures that key events can be tagged and retrieved quickly. Additionally, AI capabilities are fully enabled when paired with Wisenet AI cameras, offering advanced metadata-based search.
This NVR delivers a powerful, scalable, and installer-friendly solution ideal for medium to large surveillance deployments.
| Category | Specification |
|---|---|
| Channels & Recording | Up to 16 channels; supports up to 32MP camera resolution |
| Recording Bandwidth | Max. 140 Mbps |
| Video Output | HDMI (4K 3840×2160 @ 30Hz), VGA (1080p) |
| Compression Formats | H.265, H.264, MJPEG |
| PoE Ports | 16 × PoE+ RJ-45 (10/100Mbps), 200W total PoE budget |
| Storage | 4 TB pre-installed; 4 × SATA bays (up to 24 TB total) |
| Supported HDD Size | Up to 6 TB per drive |
| RAID Support | RAID 1 |
| Bookmark Capacity | Up to 100 bookmarks |
| Key Features | Timeline preview, Event/Alarm control, Digital PTZ, Multi-channel playback, Fisheye dewarping |
| AI Support | AI search when used with Wisenet AI cameras |
| Network Protocols | IPv4/IPv6, TCP/IP, UDP/IP, RTP/RTSP, NTP, HTTP/HTTPS, DHCP, SMTP, SNMP, DDNS, ONVIF |
| Audio | 16-channel network audio input; G.711/G.726/AAC |
| Remote Users | Search (3), Live Unicast (10), Multicast (20) |
| Mobile Support | iOS, Android |
| Failover | N+1 failover support |
| USB Ports | 2 × USB 2.0 (front), 1 × USB 3.0 (rear) |
| Alarm I/O | 4 inputs / 2 outputs |
| Operating System | Embedded Linux |
| Power Input | 100–240VAC, 50/60Hz |
| Power Consumption | Max. 310W |
| Operating Temperature | 0°C to +40°C (32°F to 104°F) |
| Dimensions | 440 × 89.8 × 428.4 mm (17.32 × 3.54 × 16.87 in) |
| Weight | 5.76 kg (12.70 lb) |
