Description
The Shure MXA902W-S-60CM is an all-in-one ceiling array microphone and loudspeaker designed to deliver exceptional audio performance in modern conferencing environments. Built for simplicity and efficiency, this 60cm square unit integrates advanced microphone array technology, a wide-dispersion loudspeaker, and powerful IntelliMix DSP into a single ceiling-mounted solution.
Engineered for meeting rooms and boardrooms, the MXA902 provides immediate single-zone coverage for up to a 20 x 20 ft space without requiring complex setup. Its Automatic Coverage technology ensures every participant is clearly heard while minimizing background noise and off-axis distractions. The integrated loudspeaker is optimized specifically for voice reproduction, ensuring consistent and intelligible audio for all participants.
With support for Dante and AES67 digital audio networking, the MXA902 simplifies installation by delivering power, control, and encrypted audio over a single PoE+ network cable. The clean ceiling-mounted design eliminates clutter while maintaining a professional and modern aesthetic. Advanced features such as Shure Audio Encryption, configurable LED status indicators, and compatibility with leading collaboration platforms make it a reliable choice for enterprise AV deployments.
| Specification | Details |
|---|---|
| Product Type | Ceiling Array Microphone and Loudspeaker (Integrated Unit) |
| Coverage Area | Up to 20 x 20 ft (6.1 x 6.1 m) single-zone coverage |
| Microphone Technology | Advanced array with Automatic Coverage |
| Loudspeaker | Integrated 2.5-inch wide-dispersion speaker optimized for voice |
| Microphone Frequency Response | 125 Hz to 20 kHz |
| Speaker Frequency Range | 120 Hz to 20 kHz |
| Maximum SPL | 95.74 dB SPL (mic), up to 88 dB SPL (speaker at 1 m) |
| Signal-to-Noise Ratio | 75.76 dB (A-weighted) |
| Dynamic Range | 77.5 dB |
| Self Noise | 18.24 dB SPL-A |
| DSP Features | Automatic Mixing, AEC, Noise Reduction, AGC, Compressor, Delay, EQ (4-band), Mute, Gain |
| Acoustic Echo Cancellation | Up to 250 ms tail length |
| Latency | 6.3 ms (speaker), 26.6 ms (mic), excluding Dante latency |
| Audio Networking | Dante and AES67 digital audio support |
| Audio I/O | 1 x RJ45 (network, audio, power, control) |
| Channel Configuration | 1 output (mic), 2 input channels (speaker) |
| Sample Rate | 48 kHz |
| Bit Depth | 24-bit |
| Power Supply | PoE+ |
| Power Consumption | 24 W maximum |
| Mounting Options | Ceiling tile (60 cm), pole, or wire rope suspension |
| Form Factor | Square, 60 cm European ceiling tile compatible |
| Color | White (paintable) |
| LED Indicator | Configurable status bar |
| Security | Shure Audio Encryption |
| Certifications | CE, FCC, ICES-003, UL2043 (Plenum), REACH, UKCA, WEEE |
| Operating Temperature | -6°C to 40°C |
| Storage Temperature | -28°C to 73°C |
| Dimensions | 593.8 x 56.04 mm |
| Weight | 5.8 kg |
| Included Accessories | Cable ties, strain-relief tabs, rubber pad set |
| Compatibility | Shure Microflex Advance ecosystem |
