Description
The ASUS RS720QA-E12-RS8U-26WEVHS is a new-generation 2U 4-node high-performance computing server engineered for HPC, AI, and data-intensive workloads. Powered by 4th Gen AMD EPYC™ 9004 Series processors with AMD 3D V-Cache™ technology, it delivers exceptional compute density, memory bandwidth, and energy efficiency. Each node supports dual SP5 sockets, 24 DDR5 DIMM slots, and dual PCIe 5.0 x16 lanes for unparalleled throughput.
With flexible air and liquid cooling options, the RS720QA-E12-RS8U achieves optimal thermal efficiency even under heavy computational loads. The integrated PFR FPGA Root-of-Trust and TPM 2.0 provide advanced hardware-level security, while ASUS Control Center (ACC) and ASMB11-iKVM simplify remote monitoring and management. Featuring redundant 80 PLUS Titanium 2600W/3200W power supplies and versatile NVMe/SATA/SAS storage, this server is optimized for dense computing environments and HPC clusters that demand performance, reliability, and scalability.
| Category | Specification |
|---|---|
| Model | ASUS RS720QA-E12-RS8U-26WEVHS |
| Form Factor | 2U Rackmount, 4-Node |
| Processor Support (Per Node) | 2 × Socket SP5 (LGA 6096), AMD EPYC™ 9004 Series (up to 400W), with AMD 3D V-Cache™ |
| Chipset / Core Logic | System on Chip (SoC) Architecture |
| Memory (Per Node) | 24 × DIMM Slots, DDR5-4800/4400 RDIMM / RDIMM 3DS, up to 6144 GB |
| Storage (Per Node) | 8 × 2.5" Hot-Swap Drive Bays (NVMe / SATA / SAS*), 2 × M.2 (up to 22110) PCIe M.2 Slots |
| RAID / Controller | SATA RAID 0, 1; Optional Broadcom SAS3008 12G Controller |
| Expansion Slots (Per Node) | 2 × PCIe Gen5 x16 (LP, CPU1) |
| Graphics | ASPEED AST2600, 64MB |
| Networking (Per Node) | 2 × 10GbE LAN Ports, 1 × Management Port |
| Management | ASUS Control Center (Classic), ASMB11-iKVM (KVM-over-IP) |
| Front I/O (Per Node) | Power, Location, Message, and LAN LEDs |
| Rear I/O (Per Node) | 2 × USB 3.2 Gen1, 1 × VGA, 1 × Mini-DP, 1 × Mgmt Port, 2 × 10GbE LAN |
| Power Supply | 1+1 Redundant 2600W / 3200W 80 PLUS Titanium CRPS |
| Cooling | Air or Liquid (Delta D2C Direct-to-Chip Technology) |
| Security | PFR FPGA Root-of-Trust, TPM 2.0 |
| Operating Systems Supported | Windows Server, RHEL, SUSE Linux, CentOS, Ubuntu, VMware |
| Dimensions (W × D × H) | 444 mm × 847 mm × 87.3 mm (17.48” × 33.35” × 3.43”) |
| Weight (Net / Gross) | 29.25 kg / 33.37 kg |
| Operating Temperature | 10°C – 35°C |
| Non-Operating Temperature / Humidity | −40°C – 60°C / 20% – 90% (non-condensing) |
| Target Applications | HPC, AI Training, Dense Compute Clusters |
