Description
The Eaton 93PX20KHW is a high-performance 20kVA/20kW online double-conversion UPS designed to provide continuous power protection for mission-critical IT, edge computing, and data center environments. Featuring unity power factor, pure sine wave output, integrated maintenance bypass, cybersecure network management, and expandable battery runtime, it ensures maximum uptime and operational efficiency.
Built for modern enterprise infrastructure, the 93PX20KHW delivers up to 97% efficiency in ECO mode, supports hardwired 208V 3-phase input/output, and includes two extended battery modules for longer runtime. Its rackmount design, hot-swappable batteries, remote management capabilities, and advanced cybersecurity features make it an ideal solution for healthcare, education, commercial, and financial applications.
Technical Specifications
| Specification | Details |
|---|---|
| Brand | Eaton |
| Model | 93PX20KHW |
| Product Type | Online Double-Conversion UPS |
| UPS Topology | Double Conversion (Online) |
| Capacity | 20kVA / 20kW |
| Power Factor | 1.0 (Unity) |
| Input Voltage | 120/208V 3-Phase Wye |
| Output Voltage | 120/208V 3-Phase Wye |
| Input Connection | Hardwired |
| Output Connection | Hardwired |
| Input Frequency | 60Hz |
| Output Frequency | 50/60Hz ±4Hz |
| Output Waveform | Pure Sine Wave |
| Voltage Regulation | ±1% |
| Input Current | 71A |
| Output Breaker | 63A 3-Pole Magnetic Breaker |
| Runtime Expansion | Yes, up to 5 Extended Battery Modules |
| Included Battery Modules | 2 Extended Battery Modules |
| Battery Type | Hot-swappable, field-replaceable |
| Network Management | Included Cybersecure Gigabit Network Card |
| Remote Management | Yes |
| Maintenance Bypass | Included |
| Display | 3.5-inch Color LCD Touchscreen |
| Energy Efficiency | Up to 97% ECO Mode |
| Rack Height | 12U |
| Form Factor | Rackmount |
| Rack Compatibility | Standard 19-inch 4-post rack |
| Cooling | Forced Air (Fans) |
| Dimensions (H × W × D) | 20.57 × 17.24 × 32.25 in |
| Audible Noise | <67 dB |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
| Warranty | 2-Year Limited Warranty |
