Description
The Eaton 93PX20KHWPAR is a high-performance 20kW, 208V three-phase online double-conversion UPS engineered for mission-critical IT, edge computing, healthcare, industrial, and data center environments. Designed with N+1 redundancy, this rackmount UPS bundle delivers exceptional power availability while protecting critical equipment from power disturbances, outages, voltage fluctuations, and electrical noise.
Its modular quick-connect architecture simplifies deployment and maintenance, while the included dual network management cards provide secure remote monitoring and management. With unity power factor output, high power density, hardwired input/output, and support for scalable battery expansion, the 93PX20KHWPAR offers an efficient, resilient, and future-ready power protection solution for demanding enterprise applications.
Technical Specifications
| Specification | Details |
|---|---|
| Brand | Eaton |
| Model | 93PX20KHWPAR |
| SKU | 93PX20KHWPAR |
| Product Type | Online Double-Conversion UPS |
| UPS Topology | Online Double-Conversion |
| Capacity | 20 kVA / 20 kW |
| Input Voltage | 208V AC Three-Phase |
| Output Voltage | 208V AC Three-Phase |
| Input Connection | Hardwired |
| Output Connection | Hardwired (5-wire) |
| Power Factor | 1.0 Unity |
| Configuration | N+1 Redundant Parallel Bundle |
| Rack Size | 21U |
| Form Factor | Rackmount |
| Efficiency | Up to 92% Online Mode, Up to 97% ECO Mode |
| Battery Type | VRLA |
| Expandable Runtime | Yes |
| Waveform | Pure Sine Wave |
| Transfer Time | Zero Transfer Time |
| Display | 3.5-inch Color LCD Touchscreen |
| Network Management | Dual NETWORK-M3 Cards Included |
| Communication Ports | RS-232, USB, EPO |
| Remote Management | SNMP / Web |
| Protection Features | Surge Protection, Backfeed Protection, Overload Protection |
| Parallel Capability | Yes (N+1 Redundancy) |
| Applications | Data Centers, Edge Computing, Healthcare, Commercial Buildings, Industrial Facilities, Enterprise IT |
