Description
The Shure AD4D-DC Axient Digital Two-Channel Wireless Receiver is engineered for mission-critical wireless audio performance in demanding professional environments. Designed for broadcast, live production, touring, and high-end installations, this receiver delivers exceptional RF stability, ultra-low latency, and pristine digital audio quality.
Operating within a wide 166 MHz tuning range (470 to 636 MHz), the AD4D-DC supports large-scale deployments with up to 120 simultaneous channels. Its True Digital Diversity ensures reliable signal reception by intelligently combining RF signals to minimize dropouts and interference. Built-in AES-256 encryption guarantees secure transmission, making it ideal for corporate, government, and high-security applications.
The integrated DC power module enables flexible deployment in mobile production setups such as broadcast trucks, while AC power redundancy ensures uninterrupted operation. With extensive network connectivity including Dante and AES3 outputs, along with remote control via ShurePlus Channels and Wireless Workbench, the AD4D-DC provides seamless integration into modern audio ecosystems.
Designed for reliability, scalability, and control, the AD4D-DC is a powerful backbone for any professional wireless audio system.
| Category | Specification |
|---|---|
| Wireless Technology | Digital UHF |
| Diversity | True Digital Diversity |
| Frequency Band | A: 470 to 636 MHz |
| Tuning Bandwidth | 166 MHz |
| RF Channel Frequencies | 6640 selectable frequencies |
| Number of Audio Channels | 2 |
| Max Transmitters per Band | Up to 120 |
| Receiver Type | 19" Rackmount (1U) |
| Max Operating Range | Up to 100 m (328 ft) |
| Latency | Selectable: 2 to 2.9 ms |
| Encryption | AES-256 secure encryption |
| Audio Outputs | 2x XLR balanced, 2x 1/4" TRS balanced, 1x AES3 digital |
| Headphone Output | 1x 1/4" TRS |
| Network Connectivity | 4x RJ45 (Dante, AES67, control, DHCP/manual IP) |
| Word Clock | 1x BNC input, 1x BNC thru |
| Antenna | 2x removable BNC external antennas |
| Gain Range | -18 to +42 dB (1 dB steps) |
| Frequency Response | 20 Hz to 20 kHz ±1 dB |
| Display | Backlit LCD |
| Mobile App Compatibility | Yes (ShurePlus Channels for iOS/Android) |
| Power Requirements | 100–240 VAC or 10.9–14.8 VDC |
| Power Consumption | 3.3 A (DC) |
| Housing | Steel chassis |
| Dimensions | 19 x 13.1 x 1.7" (483 x 333 x 44 mm) |
| Weight | 10.1 lb (4.6 kg) |
