The Shure Axient Digital AD4Q Quad-Channel Wireless Receiver delivers uncompromising RF stability, transparent audio quality, and enterprise-grade control for mission-critical wireless environments. Designed for large-scale productions, broadcast, and high-density RF deployments, this receiver leverages advanced digital wireless technology to ensure consistent, interference-resistant performance even in the most challenging conditions.
With Quadversity technology, wide tuning range, and High Density mode, the AD4Q maximizes spectral efficiency while maintaining superior signal integrity across all four channels. Integrated network control, Dante digital audio, and flexible routing options provide seamless system management and scalability for complex AV infrastructures.
Built for reliability and compliance, this TAA-compliant model is ideal for government, corporate, and regulated environments that demand secure, high-performance wireless audio solutions.
| Specification | Details |
|---|---|
| Wireless Technology | Digital UHF |
| Frequency Band | 470–636 MHz |
| Audio Channels | 4 (Quad-Channel Receiver) |
| Diversity | True Digital Diversity per Channel |
| RF Tuning Range | Up to 184 MHz |
| RF Input Connectors | BNC |
| RF Impedance | 50 Ω |
| RF Bias Voltage | 12–13.5 V DC, switchable |
| Spurious Rejection | >80 dB (typical) |
| Audio Output | XLR (balanced), 1/4" (balanced) |
| Output Level | XLR Line: +18 dBV / Mic: -12 dBV |
| Dynamic Range | Up to 130 dB (digital output) |
| Frequency Response | 20 Hz – 20 kHz |
| Total Harmonic Distortion | <0.01% |
| Gain Adjustment | -18 to +42 dB |
| Latency | As low as ~2 ms |
| Networking | 10/100/1000 Mbps Ethernet |
| Audio Networking | Dante, AES3, AES67 |
| Control Software | Wireless Workbench, ShurePlus Channels |
| Quadversity Mode | Yes (enhanced RF coverage) |
| Power Requirements | 100–240 VAC, 50–60 Hz |
| Power Consumption | Max 31 W |
| Dimensions (H x W x D) | 1.7 x 19.0 x 13.1 in |
| Weight | 10.6 lb (4.8 kg) |
| Mounting | 19" Rackmount |
| Compliance | TAA Compliant |
| Operating Range | Up to 100 m (328 ft) typical |
| Compatibility | All Shure Axient Digital transmitters |
