Description
High-Performance Stackable Switch for Next-Gen Networks
The Allied Telesis AT-x950-52XTQm Layer 3 Switch is designed for the modern enterprise network core. With 48 high-speed 10G ports and four 100G expansion slots, it offers unmatched flexibility and performance. Built for Smart City and IoT environments, this modular switch supports advanced automation through Allied Telesis' AMF and intuitive monitoring via Vista Manager™ EX and Device GUI.
Enjoy powerful Layer 3+ switching, a 1.92 Tbps switching fabric, and a 300W power profile in a compact 1U rack-mountable form. This switch is ideal for data centers, distributed enterprise cores, and high-density aggregation.
| Specification | Details |
|---|---|
| Brand | Allied Telesis |
| Series / Model | x950 Series / AT-x950-52XTQm |
| Part Number | AT-X950-52XTQM-B05 |
| Product Type | Layer 3 Modular Switch |
| Ports | 48 x 10 Gigabit Ethernet |
| Uplinks | 4 x 100 Gigabit Ethernet (QSFP+/QSFP28) |
| Media Supported | Optical Fiber, Twisted Pair |
| Ethernet Standards | 10GBase-T, 100GBase-X |
| Layer Support | Layer 3 |
| Manageable | Yes |
| Modular & Stackable | Yes |
| Expansion Slots | 4 (QSFP+/QSFP28) |
| Network Protocols | IEEE 802.1ae, 802.3ae, 802.3az, 802.3ba, etc. |
| Rack Unit | 1U |
| Power Consumption | 300W |
| Power Supply | 2 (Redundant supported and installed) |
| Input Voltage | 120V AC / 230V AC |
| Frequency | 47–63 Hz |
| Dimensions (HxWxD) | 1.7" x 17.4" x 17.7" |
| Weight | 16.98 lbs (approx.) |
| Shipping Weight | 25 lbs |
| Use Case | Enterprise, Data Center, Smart City, IoT |
| Condition | New and Factory Fresh |
