Description
Power demanding professional workloads with the AMD Ryzen Threadripper PRO 7985WX, a 64-core, 128-thread workstation processor built on AMD’s advanced Zen 4 architecture. With a 3.2 GHz base clock and boost speeds of up to 5.1 GHz, the 7985WX delivers exceptional multi-threaded performance for rendering, engineering, simulation, AI development, content creation, and other compute-intensive applications.
Designed for the sTR5 platform, this processor supports PCIe 5.0, eight-channel DDR5 RDIMM memory, and ECC for high-performance professional workstation configurations. Its massive 256 MB L3 cache helps accelerate data-intensive workloads, while AMD PRO technologies provide enterprise-focused manageability and security capabilities.
Built using TSMC 5nm FinFET technology, the Ryzen Threadripper PRO 7985WX combines high core density with advanced performance features including Precision Boost 2, Precision Boost Overdrive, AMD EXPO technology, and support for modern instruction sets such as AVX2 and AVX-512.
This OEM processor does not include a thermal solution and requires a discrete graphics card.
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | AMD |
| Processor Name | AMD Ryzen Threadripper PRO 7985WX |
| Family | Ryzen Threadripper PRO |
| Series | Ryzen Threadripper PRO 7000 WX-Series |
| Form Factor | Desktop / Workstation |
| Processor Architecture | Zen 4 |
| Former Codename | Storm Peak |
| CPU Cores | 64 |
| Threads | 128 |
| Multithreading (SMT) | Yes |
| Base Clock | 3.2 GHz |
| Max Boost Clock | Up to 5.1 GHz |
| L1 Cache | 4096 KB |
| L2 Cache | 64 MB |
| L3 Cache | 256 MB |
| Default TDP | 350W |
| CPU Core Process Technology | TSMC 5nm FinFET |
| I/O Die Process Technology | TSMC 6nm FinFET |
| CPU Compute Die (CCD) Size | 71 mm² |
| I/O Die (IOD) Size | 388 mm² |
| Package Die Count | 9 |
| CPU Socket | sTR5 |
| Supporting Chipsets | WRX90, TRX50, Pro 695 |
| Unlocked for Overclocking | Yes |
| CPU Boost Technology | Precision Boost 2 |
| Precision Boost Overdrive | Yes |
| Curve Optimizer Voltage Offsets | Yes |
| AMD EXPO Memory Overclocking | Yes |
| Instruction Set | x86-64 |
| Supported Extensions | AES, AMD-V, AVX, AVX2, AVX-512, FMA3, MMX-plus, SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64 |
| Thermal Solution | Not Included |
| Max Operating Temperature (Tjmax) | 95°C |
| PCI Express Version | PCIe 5.0 |
| Native PCIe Lanes | 148 Total / 144 Usable / 128 PCIe 5.0 |
| Native USB 3.2 Gen 2 Ports | 4 |
| Native SATA Ports | 4 |
| NVMe Support | Boot, RAID 0, RAID 1, RAID 10, RAID 5 |
| System Memory Type | DDR5 |
| Memory Subtype | RDIMM |
| Memory Channels | 8 |
| Memory Speed | Up to 5200 MT/s |
| ECC Support | Yes, Default Enabled |
| Graphics | Discrete Graphics Card Required |
| AMD PRO Technologies | Yes |
| DASH Support | Yes |
| AMD Memory Guard | Yes |
| AMD Secure Processor | Yes |
| Secure Boot | Windows Secure Boot, UEFI Secure Boot |
| Virtualization Support | AMD-V, AMD-V Nested Paging, AMD AVIC, AMD-Vi |
| Firmware TPM | Yes |
| Advanced Encryption Standard (AES-NI) | Yes |
| AMD Enhanced Virus Protection | Yes |
| Supported Operating Systems | Windows 11 64-Bit, RHEL x86 64-Bit, Ubuntu x86 64-Bit |
| Supported Technologies | AMD EXPO Technology, AMD PRO Technologies, AMD Ryzen Technologies |
| Packaging | OEM Pack |
