Description
Ensure continuous uptime and simplify serviceability with the APC SBPSU10K30FC1M1-WP Maintenance Bypass Panel. Engineered for APC Smart-UPS VT systems ranging from 10kVA to 30kVA, this 208V wall-mountable bypass panel features a 42-position circuit breaker distribution panel and wrap-around bypass capability. Designed for UL compliance with top and bottom cable entry, it allows seamless transfer of power during maintenance—maximizing availability and safety in your critical power environment.
| Category | Details |
|---|---|
| Product Type | Maintenance Bypass Panel |
| Compatible UPS Systems | APC Smart-UPS VT 10kVA – 30kVA |
| Mounting Type | Wall Mount (Not rack-mountable) |
| Main Input Voltage | 208V, 3-phase |
| Main Output Voltage | 208V, 3-phase / 120V |
| Output Connector Type | Hard Wire 5-wire (3PH + N + G) |
| Cable Entry | Top and Bottom (Standard) |
| Included Equipment | User Manual |
| Distribution Panel | 42-Position Circuit Breaker Panel |
| Max Configurable Power | 30,000W |
| Input Frequency | 50/60 Hz |
| Input Connectors | 1 × Hard Wire 5-wire (3PH + N + G) |
| Color | Black |
| Standards Compliance | UL 1778, cUL Listed, UL Listed |
| Operating Temp | 32 to 104 °F (0 to 40 °C) |
| Operating Humidity | 0 to 95% RH |
| Operating Altitude | 0 to 3,333 ft |
| Storage Conditions | 32 to 104 °F, 0 to 95% RH, up to 10,000 ft |
| Dimensions (H × W × D) | 29.49 × 37.36 × 7.76 in (74.9 × 94.9 × 19.7 cm) |
| Weight | 120.26 lb (54.55 kg) |
| GTIN | 731304218456 |
| Warranty | 1-Year Repair or Replace |
