Description
The APC Symmetra PX 100 Maintenance Bypass Panel (SYMBP100F) ensures safe and uninterrupted power continuity during UPS servicing. Designed for Symmetra PX 100 UPS systems, this 208V, 3-phase bypass panel allows seamless isolation of the UPS from the critical load, minimizing downtime during maintenance. With UL 1778 compliance and robust build quality, it offers dependable operation in demanding environments.
| Category | Details |
|---|---|
| Product Type | Maintenance Bypass Panel |
| Model | SYMBP100F |
| Compatible With | APC Symmetra PX 100 |
| Input Voltage | 208V, 3 Phase |
| Output Voltage | 208V, 3 Phase |
| Input Frequency | 60 Hz |
| Input Connection Type | Hard Wire 5-wire (3PH + N + G) |
| Color | Black |
| Height | 78.90 in (200.4 cm) |
| Width | 11.81 in (30 cm) |
| Depth | 42.13 in (107 cm) |
| Product Weight | 371.79 lb (168.64 kg) |
| Mounting Location | Front |
| Mounting Preference | No Preference |
| Standards | UL 1778 |
| Certifications | cUL Listed, CSA |
| Operating Temperature | 32–104 °F (0–40 °C) |
| Operating Humidity | 0–95% RH |
| Operating Altitude | 0–10,000 ft |
| Storage Temperature | -13–149 °F (-25–65 °C) |
| Storage Humidity | 0–95% RH |
| Storage Altitude | 0–50,000 ft |
| Lead Time | Usually Ships within 3 Weeks |
| Warranty | 1 Year (Parts Only) |
| GTIN | 731304293927 |
| Package Dimensions (HxWxL) | 84.65 x 47.64 x 33.39 in |
| Package Weight | 416.87 lb (189.09 kg) |
