Description
The Schneider Electric Galaxy VS GVSUPS15KR0B5FS is a high-efficiency 15kW 208V 3-phase UPS with modular architecture and N+1 redundancy, making it ideal for edge, small, and medium data centers, as well as commercial and industrial critical applications. It supports up to five internal 9Ah smart modular battery strings (not included), enabling customizable runtime. Comes with a 5x8 start-up service, integrated network management, and is EcoStruxure Ready.
Key Features:
-
Up to 99% efficiency in eConversion mode
-
Modular architecture for scalable availability
-
N+1 power module for fault tolerance
-
Live Swap capability with no scheduled downtime
-
Includes 1-year Secure NMC Subscription
-
EcoStruxure software integration for enhanced management
-
Includes 5x8 factory start-up service
| Specification | Details |
|---|---|
| Model Number | GVSUPS15KR0B5FS |
| Power Rating | 15 kW / 15 kVA |
| Input Voltage | 208V 3-phase (177–239V range) |
| Output Voltage | 208V 3-phase |
| Battery Support | Up to 5 x 9Ah smart modular strings |
| Battery Type | VRLA (Internal Modular) |
| Battery Voltage | 480V (384V discharge) |
| Bypass Type | Built-in static bypass |
| Efficiency (eConversion Mode) | Up to 99% |
| Output Harmonic Distortion | <1% linear / <3% non-linear loads |
| Overload Capacity | 125% for 10 mins, 150% for 60 sec |
| User Interface | Touchscreen LCD |
| Dimensions (H x W x D) | 77.56 x 21.65 x 33.35 in (197x55x84.7cm) |
| Weight | 652.6 lbs (296 kg) |
| IP Rating | IP20 |
| Noise Level | 54 dBA |
| Operating Temperature | 0–40°C (32–104°F) |
| Altitude Limit | Up to 3300 ft |
| Certifications | UL 1778, IEC 62040, CSA, FCC Class A |
| Warranty | 1-year on-site with start-up service |
