Description
The APC Galaxy VS GVSUPS40KR0B5GS is a highly efficient, scalable 40kW three-phase UPS system designed for edge computing, small to medium data centers, and mission-critical commercial or industrial infrastructure. Operating at 480V, this model includes an extra power module for N+1 redundancy and supports up to five high-capacity 9Ah smart modular battery strings (batteries not included). Equipped with EcoStruxure-ready remote monitoring, integrated network management, and a touch-screen LCD, it offers superior reliability and flexibility while optimizing space and power.
Includes 5x8 commissioning/start-up service.
| Category | Details |
|---|---|
| Model Number | GVSUPS40KR0B5GS |
| Product Type | Uninterruptible Power Supply (UPS) |
| Power Capacity | 40 kW / 40 kVA |
| Input Voltage | 480V, 3-phase |
| Output Voltage | 480V, 3-phase |
| Battery Type | VRLA Smart Modular (up to 5 x 9Ah strings) |
| Battery Voltage | 480V nominal / 384V discharge |
| Redundancy | N+1 Power Module |
| Efficiency | High efficiency, >96% (Eco Mode) |
| Frequency | 40–70 Hz |
| Harmonic Distortion | < 3% (output), < 6% (input) |
| Output Waveform | Sine wave |
| Overload Handling | 125% for 10 min, 150% for 60 sec |
| Bypass | Built-in static bypass |
| Management Interface | Touchscreen LCD, network management included |
| Dimensions (HxWxD) | 77.56 x 21.65 x 33.35 in (197 x 55 x 84.7 cm) |
| Net Weight | 652.6 lb (296 kg) |
| Noise Level | 54 dBA |
| IP Rating | IP20 |
| Compliance | UL 1778, CSA C22.2, IEC 62040, FCC Part 15 |
| Warranty | 1-Year On-Site with Authorized Start-Up |
| Included Accessories | Dust Filter, Installation Manual, Startup Svc |
