Description
The APC NetShelter SX AR3357W is a robust 48U server rack enclosure designed for high-density IT environments. It features white powder-coated steel construction with reinforced 14-gauge EIA mounting rails and 16- to 18-gauge paneling. With support for a static load of 3750 lbs and dynamic load of 2250 lbs, this enclosure ensures physical security, efficient cable management, and airflow optimization. It includes lockable doors, adjustable mounting rails, integrated cable management, casters, baying hardware, and side panels — all pre-installed for quick deployment.
Key Features:
-
Supports up to 3750 lbs static and 2250 lbs dynamic loads — ideal for heavy IT gear
-
Adjustable rails support various mounting depths and configurations
-
Lockable front/rear doors and side panels for enhanced physical security
-
Built-in high-density cable managers and improved roof access for cable routing
| Specification | Details |
|---|---|
| Model Number | AR3357W |
| Product Type | Server Rack Enclosure |
| Rack Units | 48U |
| Color | White |
| Material | Steel (14/16/18 gauge) |
| Height | 88.90 in (225.8 cm) |
| Width | 29.53 in (75 cm) |
| Depth | 47.24 in (120 cm) |
| Net Weight | 408.85 lbs (185.45 kg) |
| Max Static Load | 3750 lbs (1701 kg) |
| Max Dynamic Load | 2250 lbs (1020.6 kg) |
| Mounting Depth (Min/Max) | 10.31 / 41.26 in (26.19 / 104.8 cm) |
| Rack Width | 19 in |
| Included Accessories | Casters, leveling feet, side panels, keys, baying hardware, mounting hardware, documentation CD, user manual |
| Compliance | TAA, BAA via COTS, UL 60950, EIA-310E |
| Warranty | 5-Year Repair or Replace |
| GTIN | 731304324614 |
