Description
Drive higher rack densities without sacrificing visibility or uptime. The second-generation APC AP8888 Metered Rack PDU delivers 23 kW of three-phase power in a space-saving Zero U form factor, making it ideal for colocation suites, large enterprises, and remotely managed data-center pods.
-
±3 % revenue-grade metering (amps, volts, kW, kWh) lets you plan capacity and balance loads with confidence.
-
User-defined overload alarms (audible, visual & SNMP) help you avert unplanned downtime.
-
Real-time remote management via EcoStruxure IT™ & Secure NMC3 (HTTP S, SNMP v3, Telnet, SSH).
-
Zero-U toolless installation maximises rack space while the low-profile breakers and locking IEC outlets keep cords secure.
-
Temperature / humidity sensor port ready for environmental monitoring.
Perfect for: colocation operators, high-density HPC racks, edge or remote sites where every “U” and every amp counts.
| Attribute | Value |
|---|---|
| Model / SKU | AP8888 |
| PDU Type | Metered, 2nd Generation |
| Form Factor | Vertical Zero U (side-mount) |
| Input Plug | IEC 60309 60 A 3P+N+E |
| Input Voltage / Phases | 400 V AC, 3-phase |
| Output Voltage | 240 V AC |
| Rated Current | 32 A (40 A max) |
| Power Capacity | 23 kVA / 23 kW |
| Outlet Configuration | 30 × IEC C13, 12 × IEC C19 (locking) |
| Metering Accuracy | ±3 % (amps, volts, kW, kWh) |
| Monitoring Interfaces | Secure NMC3 (Web/HTTPS, SNMP v1/3, Telnet/SSH); EcoStruxure IT ready |
| Cord Length | 1.8 m (6 ft) |
| Dimensions (H × W × D) | 182.9 × 5.6 × 5.1 cm (72.01 × 2.20 × 2.01 in) |
| Net Weight | 10.1 kg (22.3 lb) |
| Operating Temp / RH | –5 – 60 °C / 5 – 95 % (non-condensing) |
| Certifications | UL, cUL, VCCI A, EN 55022/24, FCC Class A |
| Warranty | 2-year repair or replace |
