Description
This APC 9000 Series Switched Rack PDU offers 11.5kW power capacity and supports 200–240V inputs. Featuring 21 hybrid C13/C15 and 3 C19/C21 outlets, it provides remote monitoring, outlet-level control, and space-saving ZeroU vertical mounting. Ideal for high-density IT deployments.
| Specification | Details |
|---|---|
| Brand | APC by Schneider Electric |
| Model | APDU9981NA3 |
| PDU Type | Switched |
| Mounting Type | Vertical ZeroU |
| Mounting Mode | Not rack-mountable |
| Input Plug Type | IEC 60309 20A 3P+N+PE |
| Input Voltage | 415V 3-phase |
| Output Voltage | 208V / 240V |
| Maximum Load Capacity | 11.5 kW (11500 VA) |
| Line Rated Current / Max Line Current | 16A / 20A |
| Input Frequency | 50/60 Hz |
| Cord Length | 6 ft (1.8 m) |
| Outlets | 21 × IEC C13/C15, 3 × IEC C19/C21 |
| Communication Protocols | SNMP, Redfish |
| Network Type | 10/100/1000BASE-T |
| Color | Black |
| Height x Width x Depth | 70.51 x 2.17 x 1.81 in (179.1 x 5.5 x 4.6 cm) |
| Net Weight | 15.4 lb (7 kg) |
| Operating Temp | -5 to 60°C (23 to 140°F) |
| Storage Temp | -25 to 65°C (-13 to 149°F) |
| Relative Humidity (Op/Storage) | 5–95% |
| Certifications | UL 62368-1, cUL, FCC Part 15 Class A, PSE |
| Warranty | 3 Years Repair or Replace |
| GTIN | 731304404255 |
