Description
Maximize uptime and control in your IT environment with the APC by Schneider Electric Rack PDU 9000 Switched, a reliable and secure ZeroU power distribution unit. Designed for advanced load management, this Switched Rack PDU supports remote outlet-level switching, real-time monitoring, and outlet sequencing to reduce inrush current and prevent overloads. The 9000 Series includes enhanced cybersecurity, gigabit Ethernet, 1% metering accuracy, and support for EcoStruxure IT.
With (21) IEC C13 and (3) IEC C19 outlets and an IEC 60309 16A 2P+E plug, this PDU delivers 230V power in a vertical, space-saving ZeroU form. Built to operate in demanding environments up to 60°C, it’s ideal for high-density IT applications in data centers and edge deployments.
| Attribute | Details |
|---|---|
| Brand | APC by Schneider Electric |
| Model | APDU9959EU3 |
| Form Factor | ZeroU, Vertical Mount |
| PDU Type | Switched |
| Input Voltage | 230V AC |
| Output Voltage | 230V AC |
| Input Plug Type | IEC 60309 16A 2P+E |
| Output Receptacles | (21) IEC 60320 C13, (3) IEC 60320 C19 |
| Cord Length | 3.0 m |
| Max Load Capacity | 3700 VA |
| Max Input Current | 16 A |
| Network Connectivity | 10/100/1000BASE-T (Gigabit Ethernet) |
| Communication Protocols | SNMP, Redfish |
| Mounting | Vertical (ZeroU), Side-mountable |
| Metering Accuracy | ±1% |
| Temperature Range (Operating) | -5°C to 60°C |
| Humidity Range | 5% to 95% (non-condensing) |
| Certifications | FCC, VDE, RCM, EAC |
| Warranty | 3-Year Repair or Replace |
| Dimensions (H x W x D) | 179.4 x 5.5 x 4.6 cm |
| Net Weight | 5.61 kg |
