Description
The APC Smart-UPS X SMX2200HVNC delivers reliable, line-interactive sine wave power for servers, networking gear, and mission-critical electronics. This 2200VA/1980W UPS features a convertible 4U rack/tower design, short-depth chassis for tight spaces, and supports up to 10 external battery packs (SMX120BP) for scalable runtime. It includes a preinstalled Network Management Card (NMC) for remote monitoring via SNMP/Web and comes with an APC temperature sensor and SmartSlot support. User-selectable input voltage settings (200–240V), hot-swappable batteries, and emergency power-off (EPO) functionality make this UPS ideal for data centers and edge IT.
| Category | Details |
|---|---|
| Brand | APC by Schneider Electric |
| Model | SMX2200HVNC |
| Topology | Line Interactive |
| Power Capacity | 2200VA / 1980W |
| Form Factor | 4U Rack/Tower Convertible |
| Input Voltage | 200V – 240V |
| Input Connections | IEC 320 C20 (incl. BS1363A, Schuko EU1-16P power cords) |
| Output Voltage | 208V / 220V / 230V / 240V |
| Output Connections | 8 × IEC C13, 2 × IEC C19 |
| Waveform | Pure Sine Wave |
| Battery Type | Lead-Acid (Hot-swappable, Replaceable: APCRBC143) |
| Extendable Runtime | Supports up to 10 SMX120BP external battery packs |
| Recharge Time | 3 hours |
| Network Management | Preinstalled NMC, EcoStruxure & 3rd-party platform compatible |
| Management Interface | LCD Panel, SmartSlot, USB & RS-232 |
| Surge Energy Rating | 645 Joules |
| Mounting Hardware | Rack rails, tower feet, temperature probe included |
| Audible Noise | 55 dBA |
| Environmental | 0–40°C operating temp, 0–95% RH, up to 10,000 ft. elevation |
| Dimensions (H × W × D) | 17.01 in × 7.01 in × 19.02 in (4U) |
| Net Weight | 38.56 kg (85.01 lbs) |
| Warranty | 3 years on UPS, 2 years on battery |
| Certifications | CE, VDE, UK PSTI, RCM, EAC, TISI, IRAM |
