Description
Ensure mission-critical servers, storage, and networking gear stay protected with the APC by Schneider Electric Smart-UPS SMT2200R2X658. This high-performance 2 U line-interactive UPS delivers 2200 VA / 1980 W of pure-sine-wave power, automatic voltage regulation (AVR), and surge protection through eight NEMA outlets (6 × 5-15R, 2 × 5-20R). An intuitive LCD interface gives at-a-glance insight into load, battery charge, and estimated runtime, while smart battery management extends lifespan and enables a swift 3-hour recharge. With RoHS and REACH compliance plus field-replaceable batteries, the SMT2200R2X658 provides dependable, eco-conscious power continuity for small data centers, edge environments, and branch offices.
| Category | Details |
|---|---|
| Model / SKU | SMT2200R2X658 |
| Topology | Line-Interactive with AVR |
| Capacity | 2200 VA / 1980 W |
| Input | 120 V AC (82 – 144 V range) • 60 Hz • NEMA 5-20P plug |
| Output | 120 V AC • Pure sine wave • 63 Hz |
| Outlets | 6 × NEMA 5-15R, 2 × NEMA 5-20R (total 8 battery/surge-protected) |
| Surge Protection | 530 J |
| Runtime @ Full Load (1980 W) | 5.1 min |
| Runtime @ 50 % Load (990 W) | 15.2 min |
| Battery | Sealed lead-acid, maintenance-free • Hot-swappable • 3 h recharge |
| Indicators / Alarms | LCD for load, charge, runtime • LEDs for On-Line, On-Battery, Replace-Battery, Overload • Audible alarms |
| Communication | USB (HID) |
| Form Factor | 2 U rack-mount (rail kit sold separately) |
| Dimensions (H × W × D) | 3.4 ″ × 18.9 ″ × 26.9 ″ (86 × 480 × 684 mm) |
| Weight | 93.1 lb (42.2 kg) • Shipping: 85 lb (38.6 kg) |
| Environmental | RoHS & REACH compliant |
| Certifications | UL, FCC Class A |
| Warranty | 3-year UPS / 2-year battery (region-dependent) |
