Description
The APC Symmetra PX 100kVA Modular UPS (SY100K250DL-PD) by Schneider Electric delivers scalable, double-conversion online power protection for medium to large data centers. Designed for mission-critical infrastructure, it features a modular, 3-phase design with hot-swappable components, advanced LCD display, and high efficiency up to 96.5%. Compatible with hardwire 4-wire (3PH + G) and 5-wire (3PH + N + G) configurations. Includes factory-authorized start-up and 1-year onsite service warranty.
| Category | Details |
|---|---|
| Brand | APC by Schneider Electric |
| Model Number | SY100K250DL-PD |
| Product Line | Symmetra PX |
| UPS Type | Double Conversion Online |
| Load Capacity | 100 kVA / 100 kW |
| Input Voltage | 480V AC, 415V AC, 400V AC |
| Input Voltage Range | 408–552V / 340–460V AC |
| Output Voltage | 415V AC, 400V AC, 480V AC |
| Input Frequency | 40–70 Hz |
| Output Frequency | 50/60 Hz |
| Input Power Factor | 0.99 |
| Output Power Factor | 1.0 |
| Efficiency | 96.5% |
| Waveform | Pure Sine Wave |
| Plug Type | Hard Wire 4-wire (3PH + G), Hard Wire 5-wire (3PH + N + G) |
| Display | LCD |
| Battery Type | Valve-regulated Lead Acid |
| Battery Energy | 130,636.8 kJ |
| Recharge Time | 3.50 hours |
| Form Factor | Modular |
| Mounting | Front |
| Height | 78.4 in |
| Width | 92.5 in |
| Depth | 42.1 in |
| Weight | 5804.18 lb |
| Sound Emission | 54 dB(A) |
| Operating Temp | Up to 104°F (40°C) |
| Elevation (Max Op.) | 3333 ft |
| Package Includes | UPS, Network Management Card 2, Start-Up Service, Assembly, User Manual |
| Certifications | UL, cUL, CSA, FCC Class A, Eurobat, OSHPD, EN/IEC standards |
| Warranty | 1-Year Onsite (with Factory Start-Up Included) |
