Description
Keep mixed-voltage racks running through brownouts, surges, and outages with the APC Smart-UPS SUA5000R5TXFMR. This 7U, line-interactive unit delivers 5000 VA / 4000 W of clean sine-wave power while its built-in transformer simultaneously feeds 120 V and 208 V loads—ideal for data-center, edge, and telecom environments that host both standard IT gear and higher-voltage equipment.
Key benefits
-
Automatic Voltage Regulation (AVR) – corrects low and high mains without draining the battery, boosting system uptime.
-
Comprehensive surge & lightning protection – shields sensitive electronics from spikes and noise.
-
Precision, intelligent charging – maximises battery life and runtime efficiency.
-
Hot-swappable, user-replaceable batteries – maintain protection without powering down.
-
2-year repair/replace warranty – optional on-site and extended coverage available.
| Category | Specification |
|---|---|
| Model / SKU | SUA5000R5TXFMR |
| Topology | Line-interactive, sine-wave |
| Power Capacity | 5000 VA / 4000 W |
| Input Voltage | 208 V (NEMA L6-30P, 8 ft cord) |
| Input Frequency | 50 / 60 Hz ±5 Hz (auto-sensing) |
| Output Voltages | 120 V & 208 V (selectable) |
| Output Connections | 12 × NEMA 5-20R, 2 × NEMA L6-20R, 1 × NEMA L6-30R |
| Transfer Time | 2 ms typical |
| Efficiency | Up to 95 % (full load) |
| Battery Type | Sealed lead-acid; accommodates 2 × RBC modules (sold separately) |
| Typical Recharge | 3 h to 90 % |
| Runtime @ Full Load | ≈ 9 min 21 s (4000 W) |
| Communication Ports | RS-232 (Smart-UPS signalling), SmartSlot, LED status panel |
| Audible Noise | 53 dBA at 1 m |
| Dimensions (H × W × D) | 12.24 × 19.02 × 25.00 in / 31.1 × 48.3 × 63.5 cm |
| Rack Height | 7U |
| Weight | 320.66 lb / 145.45 kg |
| Operating Temp | 32–104 °F / 0–40 °C |
| Certifications | CSA; Lifetime equipment-protection policy $150,000 |
| Warranty | 2-year repair or replace (on-site & extended options available) |
