Description
The HPE Aruba Networking 2930F 48G PoE+ 4SFP Switch (JL557A#ABA) is a powerful Layer 3 access switch built for modern digital workplaces. It offers 48 PoE+ Gigabit Ethernet ports and 4 Gigabit SFP uplinks, enabling seamless connectivity and simplified network deployment. With robust features like RIP and OSPF routing, VSF stacking, 740W PoE+ power budget, advanced security, and cloud-ready management with Aruba Central and AirWave, this switch delivers high performance, reliability, and ease of use for enterprise edge, SMBs, and branch environments.
| Category | Specification |
|---|---|
| Product Number | JL557A#ABA |
| Product Type | Switch (Layer 3, Managed) |
| Ports | 48 x 10/100/1000 PoE+ RJ-45, 4 x SFP uplink ports |
| PoE Budget | 740 Watts |
| Stackable | Yes (Virtual Switching Framework) |
| Switching Capacity | 104 Gbps |
| Throughput | 77.4 Mpps |
| Processor | ARM Cortex-A9 1.016 GHz |
| Memory | 1 GB RAM, 4 GB Flash |
| MAC Address Table | 32K entries |
| Form Factor | Rack-mountable (1U) |
| Expansion Slots | 1 x Expansion Slot |
| Management | CLI, Web GUI, Aruba Central, AirWave, SNMP, RMON |
| Security Features | ACLs, 802.1X, RADIUS, TACACS+, DHCP snooping, SSL, MD5 |
| Routing Protocols | RIP, OSPF, Static, IPv4/IPv6, IGMP, MLD, VRRP |
| Supported Standards | IEEE 802.1x, 802.3af, 802.3at, 802.1Q, LACP, STP, MSTP |
| Power Supply | 1x Internal PSU (459W provided), 80 PLUS Silver |
| Operating Temp | 0°C to 45°C (32°F to 113°F) |
| Dimensions (W x D x H) | 17.4 x 12 x 1.7 in (1U) |
| Weight | 9.83 lbs |
| Included Accessories | Mounting ears, screws, bumper feet, cable tie |
| Warranty | Limited Lifetime |
