Description
The HPE Aruba Networking 2930M 40G 8 HPE Smart Rate PoE+ 1-slot Switch is a high-performance Layer 3 access switch engineered for the digital workplace. Designed with 40 GbE Smart Rate and PoE+ capabilities, it supports secure, unified, and high-speed connectivity for enterprise edge, branch, and SMB networks.
This 1U switch offers flexible deployment with 40 autosensing Gigabit ports, 8 Smart Rate multi-gigabit PoE+ ports (up to 60W each), dual personality SFP uplinks, and modular slots for expansion. It supports advanced Layer 3 features including Access OSPF, RIP, ACLs, and Dynamic Segmentation.
With cloud-based management (Aruba Central), robust PoE scaling (up to 1440W), and automation-ready features (REST API, OpenFlow), this switch simplifies network operations while delivering outstanding performance, scalability, and security.
| Specification | Details |
|---|---|
| Model Number | JL323A |
| Form Factor | 1U rack-mountable |
| Switch Type | Layer 3 Managed Stackable Switch |
| Ports | 36 x 10/100/1000 PoE+ RJ-454 x Dual-Personality 1G BASE-T/SFP8 x 1/2.5/5/10GBASE-T Smart Rate RJ-45 PoE+ |
| Uplink Slots | 1 uplink module slot, 1 stacking module slot |
| PoE Capability | Up to 1440W total PoE budget (with selected power supplies)Up to 60W per port |
| Processor | Dual Core ARM Cortex A9 @ 1016 MHz |
| Memory | 1 GB DDR3 SDRAM, 4 GB eMMC |
| Buffer Size | 12.38 MB (4.5 MB Ingress, 7.785 MB Egress) |
| Switching Capacity | 320 Gbps |
| Throughput | Up to 112 Mpps |
| Latency | < 3.1 µs (1G) / < 3.4 µs (10G) |
| Management | Aruba Central, AirWave, IMC, CLI, Web GUI, SNMP, REST API, Telnet, FTP |
| Redundancy | Modular redundant PoE power supplies supported |
| Supported Power Supplies | JL086A (680W), JL087A (1050W) |
| Input Voltage | 100–127 / 200–240 VAC |
| Power Consumption | 495W (JL086A) / 855W (JL087A) |
| Heat Dissipation | 145 BTU/hr |
| Dimensions (H x W x D) | 4.39 x 44.25 x 32.43 cm |
| Weight | 4.45 kg |
