Description
The HPE Aruba Networking CX 6200F 12G Class4 PoE 2G/2SFP+ 139W Switch (R8Q72A#B2B) is a high-performance Layer 3 managed switch ideal for enterprise edge, SMB, and branch office deployments. Featuring 12x Class 4 PoE+ ports and integrated 1G/10G uplinks, this rack-mountable switch delivers advanced automation, security, and analytics through the Aruba Network Analytics Engine and support for Virtual Switching Framework (VSF) stacking.
Designed with a Gen7 ASIC architecture and full Layer 3 capabilities, it supports up to 139W of PoE power, making it ideal for connecting access points, IP cameras, and IoT devices. The CX 6200 series brings intelligent edge networking with flexible manageability using Aruba Central, a web GUI, CLI, or APIs.
| Specification | Details |
|---|---|
| Model Number | R8Q72A#B2B |
| Product Series | HPE Aruba Networking CX 6200F |
| Switch Type | Managed Layer 3 |
| Total Ports | 12 x 10/100/1000 (PoE+) + 2 x 100/1000 (uplink) + 2 x 1G/10G SFP+ |
| PoE Support | IEEE 802.3af/at (Class 4), up to 30W per port, total 139W |
| Switching Capacity | 68 Gbps |
| Throughput | Up to 45.1 Mpps |
| Latency | 1G: 2.28 μs / 10G: 1.46 μs |
| Stacking Support | Yes, up to 8 switches via VSF |
| Power Supply | Fixed power supply, up to 139W PoE |
| Power Consumption | Max 170W at 230 VAC |
| Console Ports | 1x RJ-45, 1x USB-C |
| Other Interfaces | 1x USB-A Host, 1x OOBM |
| Processor | Quad Core ARM Cortex-A72 @ 1.2 GHz |
| Form Factor | Rack-mountable |
| Input Voltage | 100V–120V / 200V–240V |
