Description
The HPE Aruba Networking CX 6300M JL658A is a high-performance, stackable Layer 3 switch designed for enterprise access, aggregation, and top-of-rack (ToR) deployments. Featuring 24 SFP+ ports and 4 ultra-fast SFP56 ports, this switch delivers up to 880 Gbps switching capacity and 654 Mpps throughput. It leverages Aruba’s cloud-native AOS-CX operating system and offers advanced capabilities such as VSF stacking, real-time analytics via the Network Analytics Engine, and centralized management through Aruba Central.
Perfect for modern, mission-critical networks, this switch supports automation, intelligent segmentation, and multi-gigabit uplinks, ensuring smooth performance for demanding environments including data centers, large campuses, and enterprise edge applications.
Note: Requires separate power supply (Min 1 / Max 2: JL085A, JL757A – mix supported) and two fan trays (JL669B). Transceivers sold separately.
| Specification | Details |
|---|---|
| Product Number | JL658A |
| Ports | 24x SFP+ (1G/10G)4x SFP56 (1G/10G/25G/50G)*1x USB-C Console1x OOBM port1x USB Type-A Host |
| Stacking Support | Up to 10 switches per stack (CX 6300L stacks only with CX 6300L models) |
| Switching Capacity | 880 Gbps |
| Throughput | 654 Mpps |
| Latency | 1Gbps: 1.99 µs10Gbps: 1.49 µs25Gbps: 2.85 µs50Gbps: 2.82 µs |
| Processor | Quad Core Arm Cortex-A72 @ 1.8 GHz |
| Memory | 8 GB DDR432 GB eMMC |
| Packet Buffer | 8 MB / 16 MB / 32 MB (based on config) |
| Power Supply Options | Min 1 / Max 2: JL085A or JL757A (250W each, mix supported) |
| Fan Trays | 2 required: JL669B |
| Management | Aruba Central, CLI, SNMP v2c/v3, RMON, AirWave, Switch Multi-Edit Software |
| Dimensions (W x D x H) | 44.2 x 38.5 x 4.4 cm |
| Weight | 5.11 kg |
| Power Consumption | Idle: 51WFull Load: 85W |
| Mounting | 1U Rack-mountable |
| Transceiver Support | Min 0 / Max 24: SFP/SFP+ (1G/10G)Min 0 / Max 4: SFP/SFP+/SFP28/SFP56 (1/10/25/50G)* |
