Description
The HPE Aruba Networking CX 6400 24-port 10GBase-T and 4-port SFP56 v2 Module (R0X42C) is a high-performance, modular switch line card designed for next-gen enterprise campus and data center deployments. This line card integrates seamlessly into the Aruba CX 6400 Switch Series, providing 10GBase-T copper ports and high-speed fiber uplinks through SFP56 interfaces.
Powered by Aruba’s Gen7 ASIC architecture and AOS-CX, it supports advanced Layer 3 features including BGP, EVPN, VXLAN, and VRF. The integrated Network Analytics Engine (NAE) delivers real-time monitoring and troubleshooting capabilities. Designed for high availability, the module supports VSX for seamless failover and non-disruptive upgrades. With robust security (including MACsec), QoS, and automated management, this module is an ideal solution for organizations looking to scale their wired infrastructure with agility and intelligence.
| Specification | Details |
|---|---|
| Product Number | R0X42C |
| Port Configuration | 24 × 10GBase-T ports, 4 × SFP56 ports |
| Architecture | Gen7 ASIC, fully distributed, wire-speed switching and routing |
| Switching Capacity | Up to 28 Tbps (depends on chassis model and configuration) |
| Throughput | Up to 20 Bpps (depends on configuration) |
| PoE Support | IEEE 802.3af, 802.3at, 802.3bt PoE (depends on chassis and config) |
| Packet Buffer | 8MB shared buffer |
| Line Card Processor | Dual-Core ARM Cortex-A72 @ 1.8GHz, 4GB DDR4 memory |
| Management Options | Aruba Central, AirWave, Switch Multi-Edit Software, CX Mobile App |
| CLI & Protocols | CLI, SNMP v2c/v3, RMON |
| Input Voltage | 110–127 / 200–240 VAC (via chassis power supplies) |
| Dimensions (W×D×H) | 43.9 × 31.5 × 4.3 cm |
| Weight | 3.0 kg |
| Supported Features | Dynamic Segmentation, MACsec, VSX, VXLAN, BGP, OSPF, VRF |
