Description
The HPE Aruba CX 8100 48XF4C Ethernet Switch (R9W96A) is a next-generation switch purpose-built for enterprise campus cores and data center aggregation. With 48x 10G SFP+ and 4x 100G QSFP28 ports, this switch delivers up to 1.76 Tbps of switching capacity and supports Layer 3 routing, PoE, and high-speed optical fiber connectivity.
Backed by the modern ArubaOS-CX, it simplifies network operations with automation and real-time visibility through Aruba Network Analytics Engine (NAE), Dynamic Segmentation, and full-stack cloud management via Aruba Central. Designed to meet growing traffic and IoT demands, it includes modular power and fan support, a compact 1U form factor, and lifetime limited warranty.
Perfect for scalable, secure, and high-performance enterprise environments.
| Specification | Details |
|---|---|
| Product SKU | R9W96A |
| Product Series | HPE Aruba CX 8100 |
| Model | 48XF4C |
| Ports | 48 x 10G SFP+; 4 x 100G QSFP28 |
| Layer Support | Layer 3 |
| Media Type Supported | Optical Fiber |
| Networking Standards | IEEE 802.3 series, 802.1 series |
| Manageable | Yes |
| Modular | Yes – includes 3 fans and 2 AC PSUs |
| Power Consumption | 450W |
| PoE Support | Yes |
| Mount Type | Surface, Cabinet, Rack-mountable |
| Dimensions (H x W x D) | 1.7" x 17.4" x 16" |
| Weight | 18.50 lbs |
| Power Supply | 2 x AC (JL600A) |
| Fans | 3 x JL714A |
| Input Voltage | 120V AC / 230V AC |
| Frequency | 50/60 Hz |
| Applications | Campus, Data Center, Enterprise |
| Operating System | ArubaOS-CX (with Foundation license) |
| Warranty | Limited Lifetime Warranty |
| Compliance | RoHS |
